MEAN WELL HEP-2300-55 SMPSU 55 V 48 A 2304 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SNT CASE 2304W 55V 48A
- Output 55 V / 48 A
- Power 2304 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
431 V DC
305 V AC
- Max. output current
48 A
- Output current (max.) - rounded
48 A
- Min. input voltage
250 V DC
90 V AC
- Dim
(L x W x H) 375 x 280 x 88 mm
- Output voltage (max.)
55 V
- Connection
Screw terminal
2304 W
- No. of outputs
1 x
- Type
closed
- Weight
12500 g
- Width
280 mm
- Height
88 mm
- Length
375 mm
- Type
HEP-2300-55
- Max. temperature
+70 °C
- Min. temperature
-40 °C
