MEAN WELL HEP-240-24A Industrial PSU 24 V DC 10 A 240 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEAN CORRUGATED HEP -240-24 A 24V/10A power.
- Output 24 V DC / 10 A
- Power 240 W
- Open end cable
Technical specifications
- Product type
Industrial PSU
- Input voltage (max.)
305 V AC
- Max. output current
10 A
- Output current (max.) - rounded
10 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 244 x 68 x 38.8 mm
- Output voltage (max.)
24 V DC
- Connection
Open end cable
240 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
70 °C
- Operating temperature (min.)
-55 °C
- Weight
1300 g
- PSU features
open cable ends
- Width
68 mm
- Height
38.8 mm
- Length
244 mm
- Type
HEP-240-24A
- MTBF
171300 h
- PFC
Yes
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1562025 MEAN WELL HEP-240-24A Industrial PSU 24 V DC 10 A 240 W
User & Safety Instructions
User & Safety Instructions 1562025 MEAN WELL HEP-240-24A Industrial PSU 24 V DC 10 A 240 W
Information
Information 1562025 MEAN WELL HEP-240-24A Industrial PSU 24 V DC 10 A 240 W
Warranty Terms
Warranty Terms 1562025 MEAN WELL HEP-240-24A Industrial PSU 24 V DC 10 A 240 W
Description
The high-quality and low-noise AC/DC-industrial power supplies are available with outputs ranging from 100W to 600W available. Thanks to aluminum casing and complete filling with heat conductive silicone are the power supplies of the HEP-series for use in particularly harsh conditions: in case of high humidity or high dust occurrence, extreme temperatures, strong vibrations, high-altitude as well as with low ventilation.
Against the occurrence of dust and water have the power supplies to the IP65 degree of protection (also available with IP68), and have a vibration strength of up to 10g.
With a degree of efficiency of up to 96% and the cooling by free air convection work reliably at ambient temperatures between -55 and +70 °C. The HEP-series cover the wide input voltage range of 90 to 305 VAC and they are in output voltages of 12 V, 15 V, 24 V, 36 V, 48 V and 54 V available. How to adjust the world to industrial applications of all kinds, such as Telecommunication Systems, display and billboards in the outdoor area, oil or mine shaft systems
This text is machine translated.
Against the occurrence of dust and water have the power supplies to the IP65 degree of protection (also available with IP68), and have a vibration strength of up to 10g.
With a degree of efficiency of up to 96% and the cooling by free air convection work reliably at ambient temperatures between -55 and +70 °C. The HEP-series cover the wide input voltage range of 90 to 305 VAC and they are in output voltages of 12 V, 15 V, 24 V, 36 V, 48 V and 54 V available. How to adjust the world to industrial applications of all kinds, such as Telecommunication Systems, display and billboards in the outdoor area, oil or mine shaft systems
This text is machine translated.
Features
- Universal input
- Aluminum housing, screw terminals
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage;
- Ingebauter PFC circuit
- EN61000-3-2, -3, EN 55022, EN 60950-1
- Corresponds to 6 kV surge immunity level
