MEAN WELL HLG-320H-C1400A LED driver Constant current 320.6 W 700 - 1400 mA 114 - 229 V DC adjustable, Surge protection,
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED driverHLG-320H-C1400A
- Constant current
- 114 - 229 V DC
- 700 - 1400 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 252 x 90 x 43.8 mm
- Factory colour
Aluminium
- Output voltage (max.)
229 V DC
- Output voltage (min.)
114 V DC
- Max. output current
1400 mA
- Output current (max.) - rounded
1.4 A
- Operating voltage
115 V AC
230 V AC
- Protection class
I
- LED driver features
adjustable
Surge protection
Overvoltage
PFC circuit
Approved for use on furniture
Suitable for flammable surfaces
Outdoor
IP65
- Connection
Open end cable
- Max. power
320.6 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
700 mA
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Inputs
1
- Weight
1.880 g
- Power range
320.6 W (max)
- Type
Pulsed
- Width
90 mm
- Height
43.8 mm
- Length
252 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1713963 MEAN WELL HLG-320H-C1400A LED driver Constant current 320.6 W 700 - 1400 mA 114 - 229 V DC adjustable, Surge protection,
User & Safety Instructions
User & Safety Instructions 1713963 MEAN WELL HLG-320H-C1400A LED driver Constant current 320.6 W 700 - 1400 mA 114 - 229 V DC adjustable, Surge protection,
Warranty Terms
Warranty Terms 1713963 MEAN WELL HLG-320H-C1400A LED driver Constant current 320.6 W 700 - 1400 mA 114 - 229 V DC adjustable, Surge protection,
Description
With the Power Supplies HLG-320 H-C for LED lighting applications rounds off the output power of the HLG-C-mean corrugated family 320 W upwards.
The series HLG-320H-C with constant power are protected against short circuit, overvoltage and overheating.
The A-version of the power supply has an IP65 metal housing and the constant current is via an internal potentiometer can be set. The B-version comes in the IP67 metal housing and has a 3 in 1 dimming function.
The power supply units follow the powerful and reliable design of the HLG-C family
This text is machine translated.
The series HLG-320H-C with constant power are protected against short circuit, overvoltage and overheating.
The A-version of the power supply has an IP65 metal housing and the constant current is via an internal potentiometer can be set. The B-version comes in the IP67 metal housing and has a 3 in 1 dimming function.
The power supply units follow the powerful and reliable design of the HLG-C family
This text is machine translated.
Features
- Universal input
- Metal housing
- Constant current
- HLG-320H-C_A: IP65, constant current adjustable via internal potentiometer
- HLG-320H-C_B: IP67, 3 in 1 dimming function, constant current adjustable 0 to 10 V DC, 10 V PWM signal and resistance.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
