MEAN WELL HLG-40H-12AB LED driver Constant voltage 39.96 W 2 - 3.33 A 10.8 - 13.5 V DC dimmable, 3-in-1 dimmer, adjustab
EAN:
Part number:
Item no:
Datasheet (PDF)
4 Piece(s)
Sales and shipping:
Number
Total (€ 33.61 / piece)
€
Only 4 Piece(s) available
Highlights & Details
HLG-40H-12AB
- Constant voltage
- 10.8 - 13.5 V DC
- 2 - 3.33 A
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 171 x 61.5 x 36.8 mm
- Factory colour
Metal
- Output voltage (max.)
13.5 V DC
- Output voltage (min.)
10.8 V DC
- Test mark
MM, SELV, UL, TÜV, CB
- Max. output current
3.33 A
- Output current (max.) - rounded
3.33 A
- Operating voltage
230 V AC
115 V AC
- LED driver features
dimmable
3-in-1 dimmer
adjustable
PFC circuit
Outdoor
Surge protection
Overvoltage
Suitable for flammable surfaces
Approved for use on furniture
IP65
- Connection
Open end cable
- Max. power
39.96 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
2 A
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
90 V AC
127 V DC
- Weight
730 g
- Power range
39.96 W (max)
- Type
Pulsed
- Width
61.5 mm
- Height
36.8 mm
- Length
171 mm
- Max. temperature
+80 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2113510 MEAN WELL HLG-40H-12AB LED driver Constant voltage 39.96 W 2 - 3.33 A 10.8 - 13.5 V DC dimmable, 3-in-1 dimmer, adjustab
User & Safety Instructions
User & Safety Instructions 2113510 MEAN WELL HLG-40H-12AB LED driver Constant voltage 39.96 W 2 - 3.33 A 10.8 - 13.5 V DC dimmable, 3-in-1 dimmer, adjustab
Warranty Terms
Warranty Terms 2113510 MEAN WELL HLG-40H-12AB LED driver Constant voltage 39.96 W 2 - 3.33 A 10.8 - 13.5 V DC dimmable, 3-in-1 dimmer, adjustab
Description
Features
- Constant voltage
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overheating
- Built-in PFC circuit
- SELV compliant
- Safety Standards: EN 61347-1, EN 61347-2-13 and other
- Emc Standards: EN55015, EN61000-3-2 Class C, EN 61000-3-3, EN61547 and other
- IP65, output voltage and current limit can be set via internal potentiometer, dimming via running control cable, 3 in 1 dimming function (1...10 V DC, PWM, 100k ohm potentiometer)
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
