MEAN WELL HLG-480H-54AB LED driver Constant voltage 480.6 W 4.4 - 8.9 A 45.9 - 56.7 V DC dimmable, 3-in-1 dimmer, adjust
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 147.05 / piece)
€
Only 2 Piece(s) available
Highlights & Details
HLG-480H-54AB
- Constant voltage
- 45.9 - 56.7 V DC
- 4.4 - 8.9 A
Technical specifications
- Product type
LED driver
- Type
Constant voltage
- Dim
(L x W x H) 262 x 125 x 43.8 mm
- Factory colour
Metal
- Output voltage (max.)
56.7 V DC
- Output voltage (min.)
45.9 V DC
- Test mark
SELV, UL, TÜV, CB
- Max. output current
8.9 A
- Output current (max.) - rounded
8.9 A
- Operating voltage
230 V AC
115 V AC
- Protection class
I
- LED driver features
dimmable
3-in-1 dimmer
adjustable
PFC circuit
Outdoor
Surge protection
Overvoltage
IP65
- Connection
Open end cable
- Max. power
480.6 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
4.4 A
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
90 V AC
127 V DC
- Weight
2800 g
- Power range
480.6 W (max)
- Type
Pulsed
- Width
125 mm
- Height
43.8 mm
- Length
262 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2113479 MEAN WELL HLG-480H-54AB LED driver Constant voltage 480.6 W 4.4 - 8.9 A 45.9 - 56.7 V DC dimmable, 3-in-1 dimmer, adjust
User & Safety Instructions
User & Safety Instructions 2113479 MEAN WELL HLG-480H-54AB LED driver Constant voltage 480.6 W 4.4 - 8.9 A 45.9 - 56.7 V DC dimmable, 3-in-1 dimmer, adjust
Warranty Terms
Warranty Terms 2113479 MEAN WELL HLG-480H-54AB LED driver Constant voltage 480.6 W 4.4 - 8.9 A 45.9 - 56.7 V DC dimmable, 3-in-1 dimmer, adjust
Description
Features
- Constant voltage
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overheating
- Built-in PFC circuit
- SELV compliant
- Safety Standards: EN 61347-1, EN 61347-2-13 and other
- Emc Standards: EN55015, EN61000-3-2 Class C, EN 61000-3-3, EN61547 and other
- IP65, output voltage and current limit can be set via internal potentiometer, dimming via running control cable, 3 in 1 dimming function (1...10 V DC, PWM, 100k ohm potentiometer)
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
