Image similar
Image similar
MEAN WELL HLG-600H-24B LED driver, LED transformer Constant voltage, Constant current 600 W 25 A 12 - 24 V DC dimmable,
EAN:
Part number:
Item no:
Datasheet (PDF)
12 Piece(s)
Sales and shipping:
Number
Total (€ 201.67 / piece)
€
Highlights & Details
LED-switching power supply
- Constant voltage, Constant current
- 12 - 24 V DC
- 25 A
Technical specifications
- Protection class: IP67 dimmable
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 48.50 x 280.00 x 144.00 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
12 V DC
- Max. output current
25 A
- Output current (max.) - rounded
25 A
- Operating voltage
115 V AC
230 V AC
- Protection class
I
- LED driver features
dimmable
PFC circuit
Surge protection
IP67
- Connection
Open end cable
- Max. power
600 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Weight
3900.00 g
- Power range
600 W (max)
- Type
Synchronised
- Width
280.00 mm
- Height
144.00 mm
- Length
48.50 mm
Documents & Downloads
Datasheet
Datasheet 1293693 MEAN WELL HLG-600H-24B LED driver, LED transformer Constant voltage, Constant current 600 W 25 A 12 - 24 V DC dimmable,
User & Safety Instructions
User & Safety Instructions 1293693 MEAN WELL HLG-600H-24B LED driver, LED transformer Constant voltage, Constant current 600 W 25 A 12 - 24 V DC dimmable,
Information
Information 1293693 MEAN WELL HLG-600H-24B LED driver, LED transformer Constant voltage, Constant current 600 W 25 A 12 - 24 V DC dimmable,
Warranty Terms
Warranty Terms 1293693 MEAN WELL HLG-600H-24B LED driver, LED transformer Constant voltage, Constant current 600 W 25 A 12 - 24 V DC dimmable,
Description
LED-power supply in aluminium enclosure with an input voltage range of 90~305VAC. Mixed Mode output (voltage stable to maximum current with subsequent current stabilising) (C.V.+C.C.), protection class IP67, 3in1 dimming (potentiometer, PWM, 1-10VDC)
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- For LED lighting applications
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
