Image similar
Image similar
MEAN WELL HLG-60H-20A LED driver, LED transformer Constant voltage, Constant current 60 W 3 A 20 V DC PFC circuit, Surge
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 33.61 / piece)
€ 33.61
plus VAT.
14-day return policy included
Highlights & Details
LED-switching power supply
- Constant voltage, Constant current
- 20 V DC
- 3 A
Technical specifications
- Protection class: IP65
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 171.00 x 61.50 x 36.80 mm
- Output voltage (max.)
20 V DC
- Output voltage (min.)
20 V DC
- Test mark
EN61000-3-2. Class C. EN55015. EN61347-1. EN61347-2-13
- Max. output current
3 A
- Output current (max.) - rounded
3 A
- Operating voltage
115 V AC
230 V AC
- Protection class
IP65
- LED driver features
PFC circuit
Surge protection
adjustable
IP65
- Connection
Open end cable
- Max. power
60 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
3 A
- Input voltage (max.)
305 V AC
- Min. input voltage
90 V AC
- Weight
730.00 g
- Power (min.)
60 W
- Power range
60 up to 60 W
- Type
Synchronised
- Width
61.50 mm
- Height
36.80 mm
- Length
171.00 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1293571 MEAN WELL HLG-60H-20A LED driver, LED transformer Constant voltage, Constant current 60 W 3 A 20 V DC PFC circuit, Surge
User & Safety Instructions
User & Safety Instructions 1293571 MEAN WELL HLG-60H-20A LED driver, LED transformer Constant voltage, Constant current 60 W 3 A 20 V DC PFC circuit, Surge
Information
Information 1293571 MEAN WELL HLG-60H-20A LED driver, LED transformer Constant voltage, Constant current 60 W 3 A 20 V DC PFC circuit, Surge
Warranty Terms
Warranty Terms 1293571 MEAN WELL HLG-60H-20A LED driver, LED transformer Constant voltage, Constant current 60 W 3 A 20 V DC PFC circuit, Surge
Description
Universal input · Aluminium enclosure IP65 · Overload protection, current limiting, auto recovery · Protections: short circuit/over load/over voltage · Built-in active PFC function · Suitable for LED lighting and moving sign applications · Adjustable output voltage · Adjustable output current · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- IP65
- For LED lighting applications
- Adjustable output voltage
- Adjustable current limit
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-12
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
