MEAN WELL HVGC-240-700AB LED driver Constant current 240 W 350 - 700 mA 171.4 - 342.8 V DC adjustable, dimmable, 3-in-1
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 92.43 / piece)
€ 126.05
-27 %
€ 92.43
plus VAT.
14-day return policy included
Highlights & Details
HVGC-240-700AB
- Constant current
- 171.4 - 342.8 V DC
- 350 - 700 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 254.2 x 68 x 38.8 mm
- Factory colour
Metal
- Output voltage (max.)
342.8 V DC
- Output voltage (min.)
171.4 V DC
- Test mark
UL, ENEC, MM
- Max. output current
700 mA
- Output current (max.) - rounded
700 mA
- Operating voltage
230 V AC
- Protection class
I
- LED driver features
adjustable
dimmable
3-in-1 dimmer
PFC circuit
Outdoor
Approved for use on furniture
Suitable for flammable surfaces
Surge protection
Overvoltage
IP65
- Connection
Open end cable
- Max. power
240 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
350 mA
- Input voltage (max.)
528 V AC
747 V DC
- Min. input voltage
180 V AC
254 V DC
- Inputs
1
- Weight
1350 g
- Power range
240 W (max)
- Type
Pulsed
- Width
68 mm
- Height
38.8 mm
- Length
254.2 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2113544 MEAN WELL HVGC-240-700AB LED driver Constant current 240 W 350 - 700 mA 171.4 - 342.8 V DC adjustable, dimmable, 3-in-1
User & Safety Instructions
User & Safety Instructions 2113544 MEAN WELL HVGC-240-700AB LED driver Constant current 240 W 350 - 700 mA 171.4 - 342.8 V DC adjustable, dimmable, 3-in-1
Warranty Terms
Warranty Terms 2113544 MEAN WELL HVGC-240-700AB LED driver Constant current 240 W 350 - 700 mA 171.4 - 342.8 V DC adjustable, dimmable, 3-in-1
Description
Features
- IP65
- Current limit adjustable via internal potentiometer, dimming via running control cable, 3 in 1 dimming function (1...10 V DC, PWM, 100k ohm potentiometer)
- Constant current
- Independent operating device
- Wide-range input
- Metal housing
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overheating
- Built-in PFC circuit
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
