MEAN WELL LDH-45A-700DA LED driver Constant current 44.8 W 700 mA 24 - 64 V DC dimmable, DALI, Surge protection, Overvol
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LDH-45A-700DA
- Constant current
- 24 - 64 V DC
- 700 mA
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 75 x 53 x 22.7 mm
- Factory colour
Black
- Output voltage (max.)
64 V DC
- Output voltage (min.)
24 V DC
- Test mark
EN55015
- Max. output current
700 mA
- Output current (max.) - rounded
700 mA
- LED driver features
dimmable
DALI
Surge protection
Overvoltage
- Connection
Pins
- Max. power
44.8 W
- No. of outputs
1 x
- No. of inputs
1 x
- Output current (min.)
700 mA
- Input voltage (max.)
18 V DC
- Min. input voltage
9 V DC
- Weight
138 g
- Power (min.)
44.8 W
- Power range
44.8 up to 44.8 W
- Width
53 mm
- Height
22.7 mm
- Length
75 mm
- Max. temperature
+70 °C
- Min. temperature
-40 °C
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1837896 MEAN WELL LDH-45A-700DA LED driver Constant current 44.8 W 700 mA 24 - 64 V DC dimmable, DALI, Surge protection, Overvol
User & Safety Instructions
User & Safety Instructions 1837896 MEAN WELL LDH-45A-700DA LED driver Constant current 44.8 W 700 mA 24 - 64 V DC dimmable, DALI, Surge protection, Overvol
Warranty Terms
Warranty Terms 1837896 MEAN WELL LDH-45A-700DA LED driver Constant current 44.8 W 700 mA 24 - 64 V DC dimmable, DALI, Surge protection, Overvol
Description
Features
- DC/DC step-up converter
- Constant current output
- Wide input voltage range
- Built-in EMI filter (EN 55015)
- PWM, + analogue DIM, Remote ON/OFF
- Protection against: Short-circuit and overheating
- Suitable for controlling LED lighting
- Cooling by free convention
- LDH_DA: design with soldering pins and DALI dimming
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
