MEAN WELL LDH-65-1400 LED driver 64.4 W 1.4 A 12.5 - 46 V 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Mean Well DC/DC-LED driver 1.4 A 12.5 V 46 V 0-10 volt PWM
- 12.5 - 46 V
- 1.4 A
Technical specifications
- Connection type, input: THTConnection type, output: THTEfficiency 95 %
- Product type
LED driver
- Dim
(L x W x H) 75 x 53 x 22.70 mm
- Output voltage (max.)
46 V
- Output voltage (min.)
12.5 V
- Max. output current
1.4 A
- Output current (max.) - rounded
1.4 A
- Max. power
64.4 W
- Input voltage (max.)
32 V DC
- Min. input voltage
9.5 V DC
- Weight
152 g
- Power range
64.4 W (max)
- Width
53 mm
- Height
22.70 mm
- Length
75 mm
- Max. temperature
+60 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2749263 MEAN WELL LDH-65-1400 LED driver 64.4 W 1.4 A 12.5 - 46 V 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2749263 MEAN WELL LDH-65-1400 LED driver 64.4 W 1.4 A 12.5 - 46 V 1 pc(s)
Warranty Terms
Warranty Terms 2749263 MEAN WELL LDH-65-1400 LED driver 64.4 W 1.4 A 12.5 - 46 V 1 pc(s)
Description
Features
- Application: LightingHousing: Closed
- This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
