Image similar
Image similar
MEAN WELL LED driver Constant voltage, Constant current 184.8 W 4.4 A 42 V DC Suitable for flammable surfaces, Approved
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 53.77 / piece)
€ 53.77
plus VAT.
Only 3 Piece(s) available
Highlights & Details
MEANWELL LED Switching Power Supplies Series HLG-185H-C Metal Case IP67 Single Output CC Output: 200W
- Constant voltage, Constant current
- 42 V DC
- 4.4 A
Technical specifications
- Mixed mode output (voltage stabilized/CV or current stabilized/CC)
- Depending on the connected LED illuminant (constant current or constant voltage), the fits
- DC output of the LED power supply, within the framework of the specified technical parameters of the data sheet, the load.
- Product type
LED driver
- Type
Constant voltage
Constant current
- Dim
(L x W x H) 228 x 68 x 38.8 mm
- Factory colour
Metal
- Output voltage (max.)
42 V DC
- Test mark
MM, SELV, UL, TÜV, CB
- Max. output current
4.4 A
- Output current (max.) - rounded
4.4 A
- Operating voltage
230 V AC
115 V AC
- Protection class
I
- LED driver features
Suitable for flammable surfaces
Approved for use on furniture
Outdoor
PFC circuit
not dimmable
Surge protection
Overvoltage
IP67
- Connection
Open end cable
- Max. power
184.8 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
90 V AC
127 V DC
- Weight
1150 g
- Power range
184.8 W (max)
- Type
Pulsed
- Width
68 mm
- Height
38.8 mm
- Length
228 mm
- Max. temperature
+90 °C
- Min. temperature
-40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2237778 MEAN WELL LED driver Constant voltage, Constant current 184.8 W 4.4 A 42 V DC Suitable for flammable surfaces, Approved
User & Safety Instructions
User & Safety Instructions 2237778 MEAN WELL LED driver Constant voltage, Constant current 184.8 W 4.4 A 42 V DC Suitable for flammable surfaces, Approved
Warranty Terms
Warranty Terms 2237778 MEAN WELL LED driver Constant voltage, Constant current 184.8 W 4.4 A 42 V DC Suitable for flammable surfaces, Approved
Description
Features
- Fixed preset voltage and current
- Constant current, constant voltage
- Independant operating device
- Wide-range input
- Metal housing
- High output voltage
- Overload protection by current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overtemperature
- Built-in PFC circuit
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
