Image similar
Image similar
MEAN WELL LED transformer Constant voltage 90.24 W 1.88 A 48 V DALI 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SNT IP67 90W 48V/1.88A PWM DALI2
- Constant voltage
- 48 V
- 1.88 A
Technical specifications
- Product type
LED transformer
- Type
Constant voltage
- Dim
(L x W x H) 171 x 63 x 37.5 mm
- Output voltage (max.)
48 V
- Output voltage (min.)
48 V
- Test mark
SELV; MM-Zeichen
- Max. output current
1.88 A
- Output current (max.) - rounded
1.88 A
- Operating voltage
48 V
- Protection class
II
- LED driver features
DALI
IP67
- Connection
Braid
- Max. power
90.24 W
- No. of outputs
1 x
- Output current (min.)
1.88 A
- Input voltage (max.)
431 V DC
305 V AC
- Min. input voltage
127 V DC
90 V AC
- Weight
770 g
- Power (min.)
90.24 W
- Power range
90.24 up to 90.24 W
- Width
63 mm
- Height
37.5 mm
- Length
171 mm
- Max. temperature
+85 °C
- Min. temperature
-40 °C
Documents & Downloads
Datasheet
Datasheet 2900759 MEAN WELL LED transformer Constant voltage 90.24 W 1.88 A 48 V DALI 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2900759 MEAN WELL LED transformer Constant voltage 90.24 W 1.88 A 48 V DALI 1 pc(s)
Warranty Terms
Warranty Terms 2900759 MEAN WELL LED transformer Constant voltage 90.24 W 1.88 A 48 V DALI 1 pc(s)
Description
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
