MEAN WELL LPC-150-700 LED driver Constant current 150 W 0.7 A 107 - 215 V DC not dimmable, Surge protection 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Switching power supply
- Constant current
- 107 - 215 V DC
- 0.7 A
Technical specifications
- protection class: IP67
- Height
37.5 mm
- Length
191 mm
- Width
63 mm
IP67
- Connection
Open end cable
- LED driver features
not dimmable
Surge protection
- Type
Constant current
- Type
constant voltage
- Input voltage (max.)
305 V AC
- Min. input voltage
180 V AC
- Max. output current
0.7 A
- Output voltage (max.)
215 V DC
- Output voltage (min.)
107 V DC
- Max. power
150 W
- Operating voltage
230 V AC
- No. of inputs
1 x
- No. of outputs
1 x
- Output voltage
12 V
- Output current (details)
10 A
- Type
Synchronised
- Type
switched-mode
- Protection class
II
- Weight
740 g
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1371728 MEAN WELL LPC-150-700 LED driver Constant current 150 W 0.7 A 107 - 215 V DC not dimmable, Surge protection 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1371728 MEAN WELL LPC-150-700 LED driver Constant current 150 W 0.7 A 107 - 215 V DC not dimmable, Surge protection 1 pc(s)
Information
Information 1371728 MEAN WELL LPC-150-700 LED driver Constant current 150 W 0.7 A 107 - 215 V DC not dimmable, Surge protection 1 pc(s)
Warranty Terms
Warranty Terms 1371728 MEAN WELL LPC-150-700 LED driver Constant current 150 W 0.7 A 107 - 215 V DC not dimmable, Surge protection 1 pc(s)
Description
Constant voltage-switching power supply in waterproof plastic enclosure (IP67) with an input voltage range of 180-305 V/AC.
Features
- plastic enclosure IP67
- overload protection, pulsing hiccup shutdown, auto recovery
- protections: short circuit/over load/over voltage
- fixed output voltage
Hints
Devices only for use in equipment with another primary purpose such as photocopiers, overhead projectors and slide projectors or for scale illumination or indication purposes. Suitable for indoor use and outdoor use without direct sunlight exposure. Please avoid immerse in the water over 30 minutes.
