MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
LED-switching power supply
- Constant current
- 9 - 24 V DC
- 1.4 A
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 148 x 40 x 30 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
9 V DC
- Max. output current
1.4 A
- Output current (max.) - rounded
1.4 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
not dimmable
Surge protection
IP67
- Connection
Open end cable
- Max. power
33.6 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
264 V AC
- Min. input voltage
90 V AC
- Weight
340 g
- Power range
33.6 W (max)
- Type
Synchronised
- Width
40 mm
- Height
30 mm
- Length
148 mm
Variants(All information is without VAT, plus shipping costs)
Operating voltage
Max. power
Output current (max.) - rounded
Output voltage (max.)
Output voltage (min.)
MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
This article
115 V AC
33.6 W
1.4 A
24 V DC
9 V DC
Minimum order quantity: 1
Multiple: 1
€ 14.28*
MEAN WELL LPC-35-1050 LED driver Constant current 31.5 W 1.05 A 9 - 30 V DC not dimmable, Surge protection 1 pc(s)
115 V AC
31.5 W
1.05 A
30 V DC
9 V DC
Minimum order quantity: 1
Multiple: 1
€ 14.28*
MEAN WELL LPC-20-700 LED driver Constant current 21 W 0.7 A 9 - 30 V DC not dimmable, Surge protection 1 pc(s)
115 V AC
21 W
700 mA
30 V DC
9 V DC
Minimum order quantity: 1
Multiple: 1
€ 10.08*
MEAN WELL LPC-20-350 LED driver Constant current 16.8 W 0.35 A 9 - 48 V DC not dimmable, Surge protection 1 pc(s)
115 V AC
16.8 W
350 mA
48 V DC
9 V DC
Minimum order quantity: 1
Multiple: 1
€ 10.08*
MEAN WELL LPC-150-1050 LED driver Constant current 151 W 1.05 A 72 - 144 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
151 W
1.05 A
144 V DC
72 V DC
Minimum order quantity: 1
Multiple: 1
MEAN WELL LPC-150-1400 LED driver Constant current 151 W 1.4 A 54 - 108 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
151 W
1.4 A
108 V DC
54 V DC
Minimum order quantity: 1
Multiple: 1
MEAN WELL LPC-150-2100 LED driver Constant current 151 W 2.1 A 36 - 72 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
151 W
2.1 A
72 V DC
36 V DC
Minimum order quantity: 1
Multiple: 1
MEAN WELL LPC-150-2450 LED driver Constant current 152 W 2.45 A 31 - 62 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
152 W
2.45 A
62 V DC
31 V DC
Minimum order quantity: 1
Multiple: 1
MEAN WELL LPC-150-2800 LED driver Constant current 151 W 2.8 A 27 - 54 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
151 W
2.8 A
54 V DC
27 V DC
Minimum order quantity: 1
Multiple: 1
MEAN WELL LPC-150-3150 LED driver Constant current 151 W 3.15 A 24 - 48 V DC not dimmable, Surge protection 1 pc(s)
230 V AC
151 W
3.15 A
48 V DC
24 V DC
Minimum order quantity: 1
Multiple: 1
Documents & Downloads
Datasheet
Datasheet 1293269 MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1293269 MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
Information
Information 1293269 MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
Warranty Terms
Warranty Terms 1293269 MEAN WELL LPC-35-1400 LED driver Constant current 33.6 W 1.4 A 9 - 24 V DC not dimmable, Surge protection 1 pc(s)
Description
Universal input · Plastic enclosure IP67 · Overload protection, current limiting, auto recovery · Protections: short circuit/over load/over voltage · UL1310 Class 2 · Fixed output current
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- IP67
- EN 60950-1.
Hints
Devices only for use in equipment wirh another primary purpose such as photocopiers, overhead projectors and slide projectors or for scale illumination or indication purposes.
