MEAN WELL LRS-150-15 SMPSU 15 V DC 10 A 150 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Switching power supply case
Highlights & Details
- Output 15 V DC / 10 A
- Power 150 W
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
10 A
- Output current (max.) - rounded
10 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 165 x 100 x 40 mm
- Output voltage (max.)
15 V DC
150 W
- No. of outputs
1 x
- Type
closed
- Weight
480 g
- Type
Synchronised
- Width
100 mm
- Height
40 mm
- Length
165 mm
- Type
LRS-150-15
- Output voltage
15 V DC
- Max. power
150 W
- No. of inputs
1 x
- Inputs
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1439464 MEAN WELL LRS-150-15 SMPSU 15 V DC 10 A 150 W
User & Safety Instructions
User & Safety Instructions 1439464 MEAN WELL LRS-150-15 SMPSU 15 V DC 10 A 150 W
Information
Information 1439464 MEAN WELL LRS-150-15 SMPSU 15 V DC 10 A 150 W
Warranty Terms
Warranty Terms 1439464 MEAN WELL LRS-150-15 SMPSU 15 V DC 10 A 150 W
Description
This switching power supply has a closed design (case) and screw. The low profile recommends it. It corresponds to the EN60335-1 (PD3), EN61558-1, -2, -16 used in home appliance applications, industrial automation and controls.
Features
- Enclosed case, screw terminals
- LRS-150F: universal input
- LRS-150: 230V AC/115V AV by switch
- overload protection, pulsing hiccup shutdown, auto recovery
- protections: short circuit/over load/over voltage
- low profile
- EN60335-1 (PD3), EN61558-1, -2, -16
Hints
These power supplies are designed for installation in devices. The input voltage range (85 ~ 132 V/AC/170 ~ 264 V/AC) must be connected to the power supply according to the mains voltage.
