MEAN WELL LRS-150F-5 SMPSU 5 V DC 22 A 110 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Switching power supply case
Highlights & Details
- Output 5 V DC / 22 A
- Power 110 W
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
22 A
- Output current (max.) - rounded
22 A
- Min. input voltage
85 V AC
- Dim
(L x W x H) 170 x 100 x 35 mm
- Output voltage (max.)
5 V DC
110 W
- No. of outputs
1 x
- Type
closed
- Weight
480 g
- Type
Synchronised
- Width
100 mm
- Height
35 mm
- Length
170 mm
- Type
LRS-150F-5
- Output voltage
5 V DC
- Max. power
110 W
- No. of inputs
1 x
- Inputs
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1439473 MEAN WELL LRS-150F-5 SMPSU 5 V DC 22 A 110 W
User & Safety Instructions
User & Safety Instructions 1439473 MEAN WELL LRS-150F-5 SMPSU 5 V DC 22 A 110 W
Information
Information 1439473 MEAN WELL LRS-150F-5 SMPSU 5 V DC 22 A 110 W
Warranty Terms
Warranty Terms 1439473 MEAN WELL LRS-150F-5 SMPSU 5 V DC 22 A 110 W
Description
This switching power supply has a closed design (case) and screw. The low profile recommends it. It corresponds to the EN60335-1 (PD3), EN61558-1, -2, -16 used in home appliance applications, industrial automation and controls.
Features
- Enclosed case, screw terminals
- LRS-150F: universal input
- LRS-150: 230V AC/115V AV by switch
- overload protection, pulsing hiccup shutdown, auto recovery
- protections: short circuit/over load/over voltage
- low profile
- EN60335-1 (PD3), EN61558-1, -2, -16
Hints
These power supplies are designed for installation in devices.
