MEAN WELL MSP-1000-24 SMPSU 28 V DC 42 A 1008 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 222.69 / piece)
€ 222.69
plus VAT.
14-day return policy included
Highlights & Details
MEANWELL power supply series MSP-1000 Medical Mitgelieferte Single Output output: 1000 W
- Output 28 V DC / 42 A
- Power 1008 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
370 V DC
- Max. output current
42 A
- Output current (max.) - rounded
42 A
- Min. input voltage
90 V AC
127 V DC
- Dim
(L x W x H) 218 x 105 x 63.5 mm
- Output voltage (max.)
28 V DC
- Connection
Screw terminal
1008 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-40 °C
- Weight
1530 g
- Type
Pulsed
- Width
105 mm
- Height
63.5 mm
- Length
218 mm
- Type
MSP-1000-24
- MTBF
286300 h
- Output voltage (min.)
22 V DC
- PFC
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2113965 MEAN WELL MSP-1000-24 SMPSU 28 V DC 42 A 1008 W
User & Safety Instructions
User & Safety Instructions 2113965 MEAN WELL MSP-1000-24 SMPSU 28 V DC 42 A 1008 W
Warranty Terms
Warranty Terms 2113965 MEAN WELL MSP-1000-24 SMPSU 28 V DC 42 A 1008 W
Description
Features
- Closed design (case) with fan, screw terminals
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, overvoltage, overheating
- Built-in PFC circuit
- Parallel function (3+1)
- Low idle power when using remote signal
- Switching on and off of the output voltage via remote signal
- Sensor connection for correct voltage at the load
- DC-OK signal
- Internal auxiliary voltage, Stand-by 5 V/0.3A
