MEAN WELL N7809-2CW DC/DC converter 9 V 2 A 18 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Capacity load 680 µF
- Output voltage tolerance -3 - 3 %
- Remaining ripple 100 MVP-p
- Product type
DC/DC converter
- Type
N7809-2CW
- Min. input voltage
13 V
- Input voltage (max.)
32 V
- Output voltages
9 V
- Max. output current
2 A
- Output current (max.) - rounded
2 A
- Efficiency (max.)
95 %
18 W
- Connection
Braid
- Operating temperature (min.)
55 °C
- Operating temperature (max.)
85 °C
- Dim
(L x W x H) 11.5 x 9 x 17.5 mm
- Height
17.5 mm
- Length
11.5 mm
- Width
9 mm
- Output voltage (max.)
9 V
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3435560 MEAN WELL N7809-2CW DC/DC converter 9 V 2 A 18 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3435560 MEAN WELL N7809-2CW DC/DC converter 9 V 2 A 18 W Content 1 pc(s)
Description
The N78-2 series converters are highly efficient switching regulators that are suitable as replacements for the LM78xx/LM79xx linear regulators and whose pin-out is compatible with the LM78xx/LM79xx ICs. One of the main features is that, depending on the application, the converters can be operated in a circuit with positive or negative output voltage. It is also characterized by a high degree of efficiency of up to 96%, WAS a low power loss means a wide working temperature range of -40°C to +85°C without additional heat sink, compliance with the EN55022 radiation class B without external components, etc.
This text is machine translated.
