MEAN WELL NDR-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Switching power supply DIN-rail
Technical specifications
- Type
Synchronised
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
90 V AC
- Inputs
1
- Input voltage (max.)
264 V AC
- Max. output current
10 A
- Output current (max.) - rounded
10 A
480 W
- Output voltage (nominal)
48 V
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 170 x 150 x 125 mm
- Weight
1532 g
- Manufacturer part #
NDR-480-48
- Content
1 pc(s)
- PSU features
Surge protection
- Width
150 mm
- Height
125 mm
- Length
170 mm
- Type
NDR-480-48
- Max. power
480 W
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1439436 MEAN WELL NDR-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1439436 MEAN WELL NDR-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
Information
Information 1439436 MEAN WELL NDR-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
Warranty Terms
Warranty Terms 1439436 MEAN WELL NDR-480-48 Rail mounted PSU (DIN) 48 V 10 A 480 W No. of outputs:1 x Content 1 pc(s)
Description
This switching power supply can be mounted directly on the DIN rail in closed design with contact protected screw. It has a LED indicator for DC OK.
Features
- Direct assembly on DIN Rail
- Enclosed case, Touch-guard screw terminals
- universal input
- overload protection, current limiting, auto recovery
- protections: short circuit/over load/over voltage
- DC OK LED display
Hints
These power supplies are designed for installation in devices.
