Name: MEAN WELL NGE100 Mains PSU (fixed voltage) 5 V DC, 9 V DC, 12 V DC, 15 V DC, 20 V DC 16 A 100 W Adjustable voltage outpu
Brand: MEAN WELL
SKU: 3164218

A white charger with seven different interchangeable socket adapters suitable for various countries.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Series: NGE100
Application: ITE, household, industry
Housing: Desktop power supply
Dimensions: Length 62 mm
Dimensions: Width 30 mm
Dimensions: Height 85.5 mm
Weight: 338 g
Identification: DEKRA
MTBF 336400 h
Operation maintenance 30,000 h
Min. Operating temperature -20 °C
Max. operating temperature: 70 °C
Storage temperature, min.: -20 °C.
Storage temperature, max. 85 °C
Min. Network frequency: 47 Hz
Network frequency max. 63 Hz
Min. Input voltage AC 90 V
Max. Input voltage AC 264 V
Input current 0.8 A
Efficiency 88 %
Idle power, less than 0.3 W
Leakage current, max. 0.5 mA
Inrush current, max. 95 A
Power factor correction (PFC): 1
Power factor 0.92
Connector type, input: Adapter
Number of outputs 1
Power output: 100 W
Output voltage 5 V
Output voltage tolerance -5 - 5 %
Remaining ripple 200 MVP-p
Output current: 16 A
Overload protection 1
Overload protection version: Hiccup
Short circuit protection 0
Overvoltage protection 0
Overtemperature protection 1
Protection class: II
INSULATION VOLTAGE I/P-O/P 3,000 V
CE, IEC, PSE, UL, RCM, CCC, EAC, IC, UKCA, BSMI, KC, AS/NZ
Standards (EMC): EN 55032, class B
Standards (safety) UL 62368-1, EN 62368-1, IEC 62368-1
REACH-SVHC: No.
WEEE (waste electronics): No.
Efficiency (at 10% load): 83 %
Average efficiency: 88.5%
Output voltage selectable 0
Energy level (EU) 2019/1782 + Level VI
RoHS R - RoHS compliant
Label: NGE100
Selectable DC output voltages (V): 5; 9; 12; 15; 20

Product type: Mains PSU (fixed voltage)

Used at: Indoors

Max. output current: 16 A

Output voltage: 5 V DC
9 V DC
12 V DC
15 V DC
20 V DC

Output current (max.) - rounded: 16 A

PSU features: Adjustable voltage output

: 100 W

Dim: (L x W x H) 62.0 x 30.0 x 85.5 mm

Connection: Quick-release adapter

No. of outputs: 1 x

Input voltage (max.): 264 V AC

Min. input voltage: 90 V AC

EuP Status: Level VI

Weight: 338.0 g

Width: 30.0 mm

Height: 85.5 mm

Length: 62.0 mm

Type: NGE100

MTBF: 336400 h

Operating temperature (max.): 70 °C

Operating temperature (min.): -20 °C
