Image similar
Image similar
MEAN WELL NSP-75-24 AC/DC industrial PSU module 76.8 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Mean Well AC/DC-industrial power supply closed metal 76.8W 24V 3.2A 2*MOPP
- Output /
- Power 76.8 W
Technical specifications
- Product type
AC/DC industrial PSU module
- Input voltage (max.)
305 V AC
431 V DC
- Min. input voltage
85 V AC
120 V DC
- Dim
(L x W x H) 99 x 97 x 30 mm
76.8 W
- Efficiency to
90.5 %
- Protection class
I
- Output voltage 1
24 V
- Output current 1
3.200 A
- Operating temperature
-40 °C - +85 °C
- Weight
270 g
- Width
97 mm
- Height
30 mm
- Length
99 mm
- Type
NSP-75-24
Documents & Downloads
Datasheet
Datasheet 3557949 MEAN WELL NSP-75-24 AC/DC industrial PSU module 76.8 W
User & Safety Instructions
User & Safety Instructions 3557949 MEAN WELL NSP-75-24 AC/DC industrial PSU module 76.8 W
Description
The NSP-75 series is a 75 W AC/DC power supply with PFC-function, which is designed for high reliability and is suitable for different industries. Key features include: Compact size (99*97*30 mm) for improved space utilization in system installations, ultra-wide input range of 85-305 VAC for global compatibility, up to 92% efficiency and low standby power consumption (<0.3 W-0.5 W) for energy savings and CO2 reduction, constant current design with 200% peak performance, fanless design, large operating temperature range from -40 to +85 °C (+60 °C at full load), OVOILI compliance, integrated remote control, PCB coating, complete protection, Certifications for multiple safety standards, including 62368-1, 60601-1, 61558-1, 60335-1, 62477-1 and 61010-1 plus 2 X MOPP compliance and extremely low leakage current (<350µA)
This text is machine translated.
This text is machine translated.
Hints
These power supplies are intended for installation in terminals.
