MEAN WELL PHP-3500-380 SMPSU 380 V 10.5 A 3500 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
SNT CASE 3500W 380V 10.5A
- Output 380 V / 10.5 A
- Power 3500 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
370 V DC
264 V AC
- Max. output current
10.5 A
- Output current (max.) - rounded
10.5 A
- Min. input voltage
127 V DC
90 V AC
- Dim
(L x W x H) 380 x 141.4 x 60 mm
- Output voltage (max.)
380 V
- Connection
Screw terminal
3500 W
- No. of outputs
1 x
- Type
closed
- Weight
4500 g
- Width
141.4 mm
- Height
60 mm
- Length
380 mm
- Type
PHP-3500-380
- Max. temperature
+70 °C
- Min. temperature
-30 °C
Documents & Downloads
Datasheet
Datasheet 2900781 MEAN WELL PHP-3500-380 SMPSU 380 V 10.5 A 3500 W
User & Safety Instructions
User & Safety Instructions 2900781 MEAN WELL PHP-3500-380 SMPSU 380 V 10.5 A 3500 W
Warranty Terms
Warranty Terms 2900781 MEAN WELL PHP-3500-380 SMPSU 380 V 10.5 A 3500 W
