MEAN WELL PLD-25-1400 LED driver Constant current 25 W 1.4 A 12 - 18 V DC not dimmable 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 16.80 / piece)
€ 16.80
plus VAT.
14-day return policy included
Highlights & Details
LED-switching power supply
- Constant current
- 12 - 18 V DC
- 1.4 A
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 84.00 x 57.00 x 29.50 mm
- Output voltage (max.)
18 V DC
- Output voltage (min.)
12 V DC
- Max. output current
1.4 A
- Output current (max.) - rounded
1.4 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
not dimmable
IP30
- Connection
Open end cable
- Max. power
25 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
277 V AC
- Min. input voltage
90 V AC
- Weight
190.28 g
- Power range
25 W (max)
- Type
Synchronised
- Width
57.00 mm
- Height
29.50 mm
- Length
84.00 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1293208 MEAN WELL PLD-25-1400 LED driver Constant current 25 W 1.4 A 12 - 18 V DC not dimmable 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1293208 MEAN WELL PLD-25-1400 LED driver Constant current 25 W 1.4 A 12 - 18 V DC not dimmable 1 pc(s)
Information
Information 1293208 MEAN WELL PLD-25-1400 LED driver Constant current 25 W 1.4 A 12 - 18 V DC not dimmable 1 pc(s)
Warranty Terms
Warranty Terms 1293208 MEAN WELL PLD-25-1400 LED driver Constant current 25 W 1.4 A 12 - 18 V DC not dimmable 1 pc(s)
Description
PCD-25: AC dimmable, for leading edge and trailing edge dimmers, flexible wire terminals · PLD-25: not AC dimmable, flexible wire terminals · Plastic enclosure IP30 · Overload protection, current limiting, auto recovery · Protections: short circuit/over load/over voltage · Built-in active PFC function · Suitable for LED lighting and moving sign applications · Constant current · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Features
- Wire Connections
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- For indoor applications
- For LED lighting applications
- Constant current
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
