MEAN WELL PLM-12-500 LED driver Constant current 12 W 0.5 A 15 - 24 V DC Approved for use on furniture, Surge protection
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Only 10 Piece(s) available
Highlights & Details
LED-switching power supply
- Constant current
- 15 - 24 V DC
- 0.5 A
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 145 x 38 x 22 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
15 V DC
- Max. output current
0.5 A
- Output current (max.) - rounded
500 mA
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
Approved for use on furniture
Surge protection
IP30
- Connection
Screw terminal
- Max. power
12 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
295 V AC
- Min. input voltage
110 V AC
- Weight
118 g
- Power range
12 W (max)
- Type
Synchronised
- Width
38 mm
- Height
22 mm
- Length
145 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1293194 MEAN WELL PLM-12-500 LED driver Constant current 12 W 0.5 A 15 - 24 V DC Approved for use on furniture, Surge protection
User & Safety Instructions
User & Safety Instructions 1293194 MEAN WELL PLM-12-500 LED driver Constant current 12 W 0.5 A 15 - 24 V DC Approved for use on furniture, Surge protection
Information
Information 1293194 MEAN WELL PLM-12-500 LED driver Constant current 12 W 0.5 A 15 - 24 V DC Approved for use on furniture, Surge protection
Warranty Terms
Warranty Terms 1293194 MEAN WELL PLM-12-500 LED driver Constant current 12 W 0.5 A 15 - 24 V DC Approved for use on furniture, Surge protection
Description
Universal input · Plastic enclosure · Overload protection, current limiting, auto recovery · Protections: short circuit/over load · Built-in active PFC function · Low no load power consumption · Suitable for LED lighting and moving sign applications · Constant current · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload
- Built-in PFC circuit
- Low idle power
- For indoor applications
- For LED lighting applications
- Constant current
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
