MEAN WELL PLM-25-1050 LED driver Constant current 25 W 1.05 A 14 - 24 V DC Approved for use on furniture, Surge protecti
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€ 12.60
plus VAT.
Only 5 Piece(s) available
Highlights & Details
LED-switching power supply
- Constant current
- 14 - 24 V DC
- 1.05 A
Technical specifications
- Product type
LED driver
- Type
Constant current
- Dim
(L x W x H) 145 x 38 x 22 mm
- Output voltage (max.)
24 V DC
- Output voltage (min.)
14 V DC
- Max. output current
1.05 A
- Output current (max.) - rounded
1.05 A
- Operating voltage
115 V AC
230 V AC
- Protection class
II
- LED driver features
Approved for use on furniture
Surge protection
IP30
- Connection
Screw terminal
- Max. power
25 W
- No. of outputs
1 x
- No. of inputs
1 x
- Input voltage (max.)
295 V AC
- Min. input voltage
110 V AC
- Weight
125 g
- Power range
25 W (max)
- Type
Synchronised
- Width
38 mm
- Height
22 mm
- Length
145 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1293210 MEAN WELL PLM-25-1050 LED driver Constant current 25 W 1.05 A 14 - 24 V DC Approved for use on furniture, Surge protecti
User & Safety Instructions
User & Safety Instructions 1293210 MEAN WELL PLM-25-1050 LED driver Constant current 25 W 1.05 A 14 - 24 V DC Approved for use on furniture, Surge protecti
Information
Information 1293210 MEAN WELL PLM-25-1050 LED driver Constant current 25 W 1.05 A 14 - 24 V DC Approved for use on furniture, Surge protecti
Warranty Terms
Warranty Terms 1293210 MEAN WELL PLM-25-1050 LED driver Constant current 25 W 1.05 A 14 - 24 V DC Approved for use on furniture, Surge protecti
Description
Universal input · Plastic enclosure · Overload protection, current limiting, auto recovery · Protections: short circuit/over load · Built-in active PFC function · Low no load power consumption · Suitable for LED lighting and moving sign applications · Constant current · EN61000-3-2, Class C, EN55015, EN61347-1, EN61347-2-13
Features
- Universal input
- Overload protection through current limitation, auto recovery
- Protected against short circuit, overload
- Built-in PFC circuit
- Low idle power
- For indoor applications
- For LED lighting applications
- Constant current
- EN 61000-3-2, Class C, EN55015, EN 61347-1, EN 61347-2-13
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
