MEAN WELL PSPA-1000-48 SMPSU 48 V DC 21 A 1008 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 193.27 / piece)
€ 193.27
plus VAT.
Only 2 Piece(s) available
Highlights & Details
MEANWELL power supply series PSPA-1000 Mitgelieferte Single Output output: 1000 W parallel function
- Output 48 V DC / 21 A
- Power 1008 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
370 V DC
- Max. output current
21 A
- Output current (max.) - rounded
21 A
- Min. input voltage
90 V AC
127 V DC
- Dim
(L x W x H) 170 x 120 x 93 mm
- Output voltage (max.)
48 V DC
- Connection
Screw terminal
1008 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-20 °C
- Weight
1930 g
- PSU features
Adjustable voltage output
- Type
Pulsed
- Width
120 mm
- Height
93 mm
- Length
170 mm
- Type
PSPA-1000-48
- MTBF
2743000 h
- PFC
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2113966 MEAN WELL PSPA-1000-48 SMPSU 48 V DC 21 A 1008 W
User & Safety Instructions
User & Safety Instructions 2113966 MEAN WELL PSPA-1000-48 SMPSU 48 V DC 21 A 1008 W
Warranty Terms
Warranty Terms 2113966 MEAN WELL PSPA-1000-48 SMPSU 48 V DC 21 A 1008 W
Description
Features
- Closed design (case) with fan, screw terminals
- Universal input and parallel function
- Current Sharing up to 4000 W (3+1)
- Protected against short circuit, overload, overvoltage, overheating
- Built-in PFC circuit
- Switching on and off of the output voltage via remote signal
- Sensor connection for correct voltage at the load
Hints
These power supplies are designed for installation in devices.
