MEAN WELL RSP-1000-27 SMPSU 30 V DC 37 A 999 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEANWELL Power Supply Units RSP -1000-27 999 W 27V/DC 37A
- Output 30 V DC / 37 A
- Power 999 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
37 A
- Output current (max.) - rounded
37 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 295 x 127 x 41 mm
- Output voltage (max.)
30 V DC
- Connection
Screw terminal
999 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+60 °C
- Operating temperature (min.)
-20 °C
- Weight
1.950 g
- PSU features
Adjustable voltage output
- Width
127 mm
- Height
41 mm
- Length
295 mm
- Type
RSP-1000-27
- MTBF
313.100 h
- Output current (min.)
0 A
- Output voltage (min.)
24 V DC
- PFC
Yes
- Max. temperature
+60 °C
- Min. temperature
-20 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1837914 MEAN WELL RSP-1000-27 SMPSU 30 V DC 37 A 999 W
User & Safety Instructions
User & Safety Instructions 1837914 MEAN WELL RSP-1000-27 SMPSU 30 V DC 37 A 999 W
Warranty Terms
Warranty Terms 1837914 MEAN WELL RSP-1000-27 SMPSU 30 V DC 37 A 999 W
Description
Features
- Closed design (case) with fan
- Screw connections
- Universal input
- Overload protection through current limitation
- Auto Recovery
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- low-height;
- Parallel function
- Active power distribution of up to 4000 W (3+1 power supplies)
- Switching on and off of the output voltage via remote signal
- Sensor connection for correct voltage at the load
- DC-OK signal
- Internal auxiliary voltage 5V/0.5A
