MEAN WELL RSP-1500-5 SMPSU 5.5 V DC 240 A 1200 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
MEANWELL Power Supply Units RSP-150 0-15 1200 W 5 V/DC 240A
- Output 5.5 V DC / 240 A
- Power 1200 W
- Screw terminal
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
264 V AC
- Max. output current
240 A
- Output current (max.) - rounded
240 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 278 x 127 x 83.5 mm
- Output voltage (max.)
5.5 V DC
- Connection
Screw terminal
1200 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
+70 °C
- Operating temperature (min.)
-20 °C
- Weight
3.000 g
- PSU features
Adjustable voltage output
- Width
127 mm
- Height
83.5 mm
- Length
278 mm
- Type
RSP-1500-5
- MTBF
265.300 h
- Output current (min.)
0 A
- Output voltage (min.)
4.5 V DC
- PFC
Yes
- Max. temperature
+70 °C
- Min. temperature
-20 °C
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1838055 MEAN WELL RSP-1500-5 SMPSU 5.5 V DC 240 A 1200 W
User & Safety Instructions
User & Safety Instructions 1838055 MEAN WELL RSP-1500-5 SMPSU 5.5 V DC 240 A 1200 W
Warranty Terms
Warranty Terms 1838055 MEAN WELL RSP-1500-5 SMPSU 5.5 V DC 240 A 1200 W
Description
Features
- Closed design (case) with fan, screw terminals
- Universal input
- Overload protection through current limitation, switching off after 5 seconds
- Protected against short circuit, overload, over voltage
- Built-in PFC circuit
- low-height;
- Parallel function
- Active power distribution of up to 6000 W (3+1 power supplies)
- Switching on and off of the output voltage via remote signal
- Power failure indicator
- Sensor connection for correct voltage at the load
- Internal auxiliary voltage 12 V/0.1A
