MEAN WELL SMU01L-15N DC/DC converter 15 V 0.067 A 1 W No. of outputs: 1 x Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- MTBF 2,000,000 h
- Input voltage ratio 1:1
- Power output 1 W
- Product type
DC/DC converter
- Type
SMU01L-15N
- Min. input voltage
4.5 V
- No. of outputs
1 x
- Output voltages
15 V
- Max. output current
0.067 A
- Output current (max.) - rounded
67 mA
- Efficiency (max.)
86 %
1 W
- Insulation voltage
1500 V DC
- Enclosure
SIP 4
- Connection
THT
- PSU features
DC-to-DC converter
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+150 °C
- Dim
(L x W x H) 11.7 x 6 x 10.2 mm
- Height
10.2 mm
- Length
11.7 mm
- Width
6 mm
- Output voltage (max.)
15 V
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3431170 MEAN WELL SMU01L-15N DC/DC converter 15 V 0.067 A 1 W No. of outputs: 1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3431170 MEAN WELL SMU01L-15N DC/DC converter 15 V 0.067 A 1 W No. of outputs: 1 x Content 1 pc(s)
Description
The series SMU01-N is an unregulated 1 Watt DC/DC converter in the standard SIP4 plastic housing with an input voltage range of +10%. It features an insulated voltage of 1500VDC, an extremely low no-load current and a wide operating temperature range of -40 to +105°C and is suitable for all types of systems such as industrial control systems, automation systems etc.
