MEAN WELL SPB09W8-12 DC/DC converter 12 V 0.750 A 9 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- REMOTE Function
- Product type
DC/DC converter
- Type
SPB09W8-12
- Output voltages
12 V
- Max. output current
0.750 A
- Output current (max.) - rounded
750 mA
9 W
- Enclosure
SIP 8
- Dim
(L x W x H) 24 x 9.6 x 11.2 mm
- Height
11.2 mm
- Length
24 mm
- Width
9.6 mm
- RoHS-compliant
Yes
- Weight
5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3556682 MEAN WELL SPB09W8-12 DC/DC converter 12 V 0.750 A 9 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3556682 MEAN WELL SPB09W8-12 DC/DC converter 12 V 0.750 A 9 W Content 1 pc(s)
Description
The SPB0O9W8 series is an isolated and regulated DC/DC converter of the module type with 9 W in the SIP8 casing. They have international standard pins, a high degree of efficiency of up to 87%, a wide operating temperature range of -40-+90'C, 1.5KVdc I/P-O/P isolation voltage, continuous short-circuit protection, etc. The models take into account various 9-75Vdc 8:1 ultra wide input voltages, and various output voltages, 3.3V/5V/9V/12V/15V/24V for single output suitable for all types of systems, such as industrial control, telecommunications, distributed power architecture, and so on.
