MEAN WELL SPBW03W8-03 DC/DC converter 3.3 V 0.700 A 3 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- REMOTE Function
- Product type
DC/DC converter
- Type
SPBW03W8-03
- Output voltages
3.3 V
- Max. output current
0.700 A
- Output current (max.) - rounded
700 mA
3 W
- Enclosure
SIP 8
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- RoHS-compliant
Yes
- Weight
4.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3556685 MEAN WELL SPBW03W8-03 DC/DC converter 3.3 V 0.700 A 3 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3556685 MEAN WELL SPBW03W8-03 DC/DC converter 3.3 V 0.700 A 3 W Content 1 pc(s)
Description
The SPBWO03W8 series is an isolated and regulated 3W module DC-DC converter with SIP8 package. It has international standard pins, a high degree of efficiency of up to 85%, a wide operating temperature range of -40°+90°C, 3KVDE I/P-O/P insulation voltage, compliance with BS EN/EN55022 radiated class A without additional components, permanent short circuit protection, etc. SPBW03W8 has an ultra-wide input range of 8:1 (9-75Vdc) and various output voltages, 3.3V/5V/12V/15V for single output suitable for all types of systems, such as industrial control, telecommunications, distributed power systems, etc.
