MEAN WELL XDR-240E-48 Rail mounted PSU (DIN) 48 V 5 A 240 W Content 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 50.41 / piece)
€ 50.41
plus VAT.
14-day return policy included
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
85 V
- Input voltage (max.)
264 V
- Max. output current
5 A
- Output current (max.) - rounded
5 A
240 W
- Output type (power supply units)
Adjustable
- Output voltage (nominal)
48 V
- Connection
Screw terminal
- Dim
(L x W x H) 116 x 40 x 125.2 mm
- Output voltage (max.)
48 V
- Operating temperature (max.)
+70 °C
- Max. operating temperature (derating)
70 °C
- Min. operating temperature (derating)
-40 °C
- Operating temperature (min.)
-40 °C
- Manufacturer part #
XDR-240E-48
- Content
1 pc(s)
- PSU features
Adjustable voltage output
- Width
40 mm
- Height
125.2 mm
- Length
116 mm
Protection class I
- Max. temperature
-40 °C
- Min. temperature
+70 °C
- Type
XDR-240E-48
- Efficiency
95.5 %
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3431213 MEAN WELL XDR-240E-48 Rail mounted PSU (DIN) 48 V 5 A 240 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3431213 MEAN WELL XDR-240E-48 Rail mounted PSU (DIN) 48 V 5 A 240 W Content 1 pc(s)
