MEAN WELL XLC-60-48-BS LED driver Constant voltage 60.0 W 1.25 A 48 V PFC circuit 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Mean Well XLC-60 LED-SNT plastic case
- Constant voltage
- 48 V
- 1.25 A
Technical specifications
- XLC-60 series
- Application: Lighting
- Dimensions: Length 176 mm
- Dimensions: Width 45 mm
- Dimensions: Height 32 mm
- Weight: 415 g.
- Identification: MM characters; SELV
- Min. Operating temperature -25 °C
- Max. operating temperature: 90 °C
- Storage temperature, min.: -40 °C.
- Storage temperature, max. 80 °C
- Min. Network frequency: 47 Hz
- Network frequency max. 63 Hz
- Min. Input voltage AC 100 V
- Max. Input voltage AC 305 V
- Min. Input voltage DC 155 V.
- Max. Input voltage DC 431 V.
- Input current 0.35 A
- Efficiency 88 %
- Leakage current, max. 0.75 mA
- Inrush current, max. 15 A
- Power factor correction (PFC): 1
- Power factor 0.95
- Connector type, input: Plug-in terminal
- Number of outputs 1
- Power output: 60 W
- Output voltage 48 V
- Output current: 1.25 A
- Overload protection 1
- Overload protection version: Hiccup
- Short circuit protection 1
- Overvoltage protection 1
- Overtemperature protection 1
- Connector type, output: Plug-in terminal
- Protection class: II
- INSULATION VOLTAGE I/P-O/P 3,750 V
- APPROVALS CE, IEC, RCM, EAC, CCC,ENEC,EN,UKCA
- Standards (EMC) EN 55015
- Standards (security): EN 61347-1, EN 61347-2-13, IEC 61347-1, IEC 61347-2-13
- REACH-SVHC: No.
- WEEE (waste electronics): No.
- RoHS R - RoHS compliant
- Operating mode CV
- Dimmable:1
- Interfaces: 0-10 Volt, PWM, resistive
- Power consumption in standby mode (PSB), less than: 0.5 W.
- Number of max. B16 circuit breaker: 25
- Number of max. at C16 Circuit breaker: 36
- Output current selectable: 0
- Product type
LED driver
- Type
Constant voltage
- Operating current
0.35 A
- Dim
(L x W x H) 176.0 x 45.0 x 32.0 mm
- Output voltage (max.)
48 V
- Test mark
CE.IEC.RCM.EAC.CCC.ENEC.EN.UKCA
- Max. output current
1.25 A
- Output current (max.) - rounded
1.25 A
- Protection class
II
- LED driver features
PFC circuit
- Connection
Plug & Clip
- Max. power
60.0 W
- No. of outputs
1 x
- Input voltage (max.)
305 V
- Min. input voltage
100 V
- Weight
415.0 g
- Power range
60.0 W (max)
- Width
45.0 mm
- Height
32.0 mm
- Length
176.0 mm
- Max. temperature
90 °C
- Min. temperature
-25 °C
- Operating temperature (max.)
90 °C
- Operating temperature (min.)
-25 °C
- Input voltage
431 V
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 3164345 MEAN WELL XLC-60-48-BS LED driver Constant voltage 60.0 W 1.25 A 48 V PFC circuit 1 pc(s)
Datasheet 3164345 MEAN WELL XLC-60-48-BS LED driver Constant voltage 60.0 W 1.25 A 48 V PFC circuit 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3164345 MEAN WELL XLC-60-48-BS LED driver Constant voltage 60.0 W 1.25 A 48 V PFC circuit 1 pc(s)
Warranty Terms
Warranty Terms 3164345 MEAN WELL XLC-60-48-BS LED driver Constant voltage 60.0 W 1.25 A 48 V PFC circuit 1 pc(s)
Description
DC-enabled, flicker-free, emergency light control device, independent operating device
This text is machine translated.
This text is machine translated.
Hints
Caution!
Make sure you pick an LED driver/transformer that comes with the appropriate power rating.
Choose a driver/transformer that supplies approx. 30 pecent more watttage, as the current consumption (i.e. amperage) of the LEDs is key, and not the power rating of the LED provided by the LED manufacturer.
Keep in mind that the switch-on surge tend to be much higher.
