Metz Connect Kabel Metz Connect Kabel N/A 130E405042-E Plug Black 1 pc(s) 130E405042-E Plug Black 1 pc(s)
EAN:
Part number:
Item no:
Product type
RJ45 plug
Connector type
Plug
Specification
CAT 6A
Connector standard
RJ45
Type
Kabel
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 30.24
3
4% = € 1.32
€ 28.92
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 30.24 / piece)
€ 30.24
plus VAT.
14-day return policy included
Metz Connect Kabel N/A 130E405042-E Plug Black 1 pc(s)
Highlights & Details
- RJ45 MugNetwork connectionModular plug connectorCat. 6A plugCat. 6A plugCat.6A connectionCat. 6A connectionBTR plugBTR Netcom
Technical specifications
- Type
Kabel
- Product type
RJ45 plug
- Connector type
Plug
CAT 6A
- Connector standard
RJ45
- AWG max.
22
- AWG (min.)
27
- Connection
RJ45
- Type A
RJ45 8p8c plug
- Type B
RJ45 8p8c plug
- No. of ports
1 x
- Weight
0.0350 kg
- Factory colour
Black
- Content
1 pc(s)
- Contact material
Copper
- Material
Zinc (die-cast)
- Width
13.80 mm
- Height
27.50 mm
- Length
61.70 mm
- Features
+ strain relief
- Max. temperature
+70 °C
- Min. temperature
-40 °C
- Seal type
Snap-in
- Version
Cable
- Cable use
RJ45
- Connection type
RJ45
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2860684 Metz Connect Kabel Metz Connect Kabel N/A 130E405042-E Plug Black 1 pc(s) 130E405042-E Plug Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2860684 Metz Connect Kabel Metz Connect Kabel N/A 130E405042-E Plug Black 1 pc(s) 130E405042-E Plug Black 1 pc(s)
Description
Field-configurable RJ45 plug Cat.6, A/Class EA, fully shielded and multi-port capability, cable routing variable, freely selectable (360°), Simplest assembly - connectable without special tools, wire connection stranded conductor AWG 27/7 - 22/7, wire diameter 0.46 - 0.76 mm, wire connection solid wire AWG 26/1 - 22/1, wire diameter 0.4 - 0.64 mm, wire characteristics Cat. 6, A to ISO/IEC 11801 Ed. 2.2:2011-06, compliance with class E, A to ISO/IEC 11801 Ed. 2.2:2011-06, DIN EN 50173 09-1-2011, Suitable for 10GBit Ethernet (IEEE 802.3an), remote power (PoE, PoE plus, UPoE and 4PPoE) and HDBaseT); degree of protection IP20, suitable for cable sheath diameters from 5.5 to 10.5 mm, industrial-grade housing made of zinc die-cast, strain relief via snap-on clip directly at the loading piece, protected locking hook, re-connectable.
