Mini relay Schneider Electric RXM4LB2P7 4 change-overs 230 V AC 10 pc(s)
EAN:
Part number:
Item no:
Product type
Mini relay
Operating voltage
230 V AC
Contact type
4 change-overs
Type
RXM4LB2P7
Permanent current (max.)
3 A
Datasheet (PDF)
Number (Package size 10 pc(s))
Total (€ 6.72 / piece)
€ 67.22
plus VAT.
14-day return policy included
Technical specifications
- Product type
Mini relay
- Type
RXM4LB2P7
- Operating voltage
230 V AC
- Permanent current (max.)
3 A
- Contact type
4 change-overs
- Features
+ LED
- Content
10 pc(s)
FALSE
FALSE
Other
Plug-in connection
230-230.0 V
AC
TRUE
AC
Other
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3305112 Mini relay Schneider Electric RXM4LB2P7 4 change-overs 230 V AC 10 pc(s)
User & Safety Instructions
User & Safety Instructions 3305112 Mini relay Schneider Electric RXM4LB2P7 4 change-overs 230 V AC 10 pc(s)
Description
The Easy RXMLB miniature relays are part of the electromechanical relays of the Harmony series and are especially suitable for simple automation systems. This plug relay has 4 changeover contacts, a rated current of 3A and requires a 230V AC input voltage. The mounting is done thereby with an additional RXZE base, which has a mixed contact arrangement. For additional protection against vibrations, a metal clamp RXZ can be attached to the base. In addition, it has a transparent cover and an LED for visual inspection of the status of the contacts. The product complies with international standards and certifications such as IEC and CE. Thanks to the Green Premium eco-label, you can get detailed information on material content, environmental impact and recycling management that support your sustainability goals.
