Mobotix Mobotix Mx-A-ETP1A-2601-SET - Netzwerkextender Mx-A-ETP1A-2601-SET Media converter
EAN:
Part number:
Item no:
Datasheet (PDF)
Mobotix Media Converter Set Ethernet (PoE+) - Two-wire
Highlights & Details
- Ethernet via 2-wire communication according to IEEE1901 standard
- 2-wire data and power over cable (UTP, COM, Power line, etc.)
- Does not support twisted/twisted 2-wire cables over long distances
- Data distance up to 600 m.
- PoE-distance up to 300 m
Technical specifications
- Interface 2-wire: 1 x terminal block - Ethernet via 2-wire (T-LinX)
- Interface Ethernet 1 x RJ45 - 10/100 Base-T with Auto-Detect MDIX
- Power ETP-2601T:
- Input:T-Linx or DC 1 2V~57 V
- PoE output: IEEE802.3af (PoE), IEEE802.3at (PoE+), extra PoE up to 60 W
- PoE input: Not supported
- Power ETP-2601R:
- Input: PoE-switch or DC48 V~57 V.
- PoE output: PoE is not supported, only Power over 2-Wire
- PoE input: Up to 25.5W (PD)
- Product type
Media converter
- Weight
102 g
- Width
61.6 mm
- Height
24 mm
- Length
80.4 mm
- Factory colour
Black
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2973155 Mobotix Mobotix Mx-A-ETP1A-2601-SET - Netzwerkextender Mx-A-ETP1A-2601-SET Media converter
User & Safety Instructions
User & Safety Instructions 2973155 Mobotix Mobotix Mx-A-ETP1A-2601-SET - Netzwerkextender Mx-A-ETP1A-2601-SET Media converter
Description
The ETP-2601 series is a high-speed Ethernet and PoE extender over long distances, which enables the transmission of the Ethernet signal and PoE via a 2-wire cable (twisted-pair cable, COM, Powerline) in different situations.
It is a cost-effective and time-saving solution for migrating an existing analogue system to an IP-based system, since ETP-2601 supports easy installation using the existing cable.
With the remote transmission function the device can easily overcome the distance limitation of 100 meters and considerably reduce the construction costs compared to the fiber-optic configuration.
This text is machine translated.
It is a cost-effective and time-saving solution for migrating an existing analogue system to an IP-based system, since ETP-2601 supports easy installation using the existing cable.
With the remote transmission function the device can easily overcome the distance limitation of 100 meters and considerably reduce the construction costs compared to the fiber-optic configuration.
This text is machine translated.
Features
- Max. 95 Mbps bandwidth (270 Mbps between Series 2 Intercoaxial models)
- 10/100 full duplex
- 128-bit AES network encryption
- Supports Multi-connection (daisy chain, star, etc.)
- PoE, PoE+, extra PoE (max. 60W output) (only ETP-2601T)
- PoE ON/OFF switch (ETP-2601T only)
- LED display (data, power supply, connection, PoE)
- Plug & Play
- Overvoltage protection
- Supports PoE+ input (25.5W) of PSE devices - ETP-2601R only
- Slim design
