Molex 702461004 Pin strip Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Tray
EAN:
Part number:
Item no:
Packaging type
Tray
Product type
Pin strip
CS
2.54 mm
No. of rows
2
Content
1 pc(s)
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 0.69
10
9% = € 0.06
€ 0.63
25
12% = € 0.08
€ 0.61
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 0.69 / piece)
€ 1.35
-49 %
€ 0.69
plus VAT.
14-day return policy included
Highlights & Details
C GRID
- Total number of pins 10
- No. of rows 2
- Content 1 pc(s)
Our service for you
Technical specifications
- Please review product datasheet for further information.
- Packaging type
Tray
- Product type
Pin strip
- CS
2.54 mm
- No. of rows
2
- Total number of pins
10
- Nominal voltage
250 V DC
- Nominal current
2.5 A
- Contact material
Brass
- Content
1 pc(s)
- Connection
Soldering
- Type
Molex MOL Power & Signal Sol.
- Coating thickness (PCB side)
1.905 µm
- Connector coating thickness
0.127 µm
- Manufacturer part #
702461004
- Board contact surface
Tin
- Connector contact surface
Gold
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
+120 °C
- Min. temperature
-55 °C
- Engineering Part No
70246-1004
- Engineering Series Name
2.54MM C-GRID SHRDED
- Engineering Series No
70246
Documents & Downloads
Datasheet
Datasheet 2449877 Molex 702461004 Pin strip Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2449877 Molex 702461004 Pin strip Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Tray
Circuit diagramm
Circuit diagramm 2449877 Molex 702461004 Pin strip Contact spacing: 2.54 mm Total number of pins: 10 No. of rows: 2 1 pc(s) Tray
Description
2.54mm Pitch C-Grid Header, Low Profile, Dual Row, Vertical, Shrouded, 10 Circuits, 0.13µm Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating
