Molex 936000037 Cable gland M20 x 1.5 Polyamide, Steel, Elastomer Grey-white (RAL 7035) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Cable gland
External thread
M20 x 1.5
Type
Basic
Material
Polyamide
Steel
Elastomer
Clamp Ø
3.5 mm
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
50
-
€ 2.09
10
8% = € 0.16
€ 1.93
25
11% = € 0.22
€ 1.87
Volume discounts vary depending on the seller
You save € 11.00
Number
Minimum order quantity: 50
Multiple: 50
Total (€ 1.87 / piece)
€ 3.44
-46 %
€ 93.50
plus VAT.
14-day return policy included
Highlights & Details
Heavy duty connector
- GWconnect Plastic Cable Gland, with Washer and Gaskets, M20x1.5 Thread, Grey
- This text is machine translated.
Our service for you
Technical specifications
- Material - coating: Zinc
- Product type
Cable gland
- Factory colour
Grey-white (RAL 7035)
- External thread
M20 x 1.5
- Type
Basic
- Material
Polyamide
Steel
Elastomer
- Clamp Ø
3.5 mm
- Terminal Ø (max.)
12.5 mm
- Min. temperature
-40 °C
- Max. temperature
+125 °C
IP66
- Weight
11 g
- Content
1 pc(s)
- RoHS-compliant
Yes
- Manufacturer part #
936000037
- Type
MWE Industrial Solution
- Engineering Part No
7000.6839.0
- Engineering Series Name
Gland, fitting&acc.
- Engineering Series No
93600
Documents & Downloads
Datasheet
Datasheet 2450809 Molex 936000037 Cable gland M20 x 1.5 Polyamide, Steel, Elastomer Grey-white (RAL 7035) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2450809 Molex 936000037 Cable gland M20 x 1.5 Polyamide, Steel, Elastomer Grey-white (RAL 7035) 1 pc(s)
Description
GWconnect Plastic Cable Gland, with Washer and Gaskets, M20x1.5 Thread, Grey
