Molex Built-in SIL socket (standard) Total number of pins 14 Contact spacing: 2 mm 873401424 38 pc(s) Tube
EAN:
Part number:
Item no:
Product type
Built-in SIL socket (standard)
No. of rows
2
CS
2 mm
Total number of pins
14
Packaging type
Tube
Datasheet (PDF)
Quantity (Set(s))
Unit Price
Package size (plus VAT.)
1
1 ST = € 2.90
€ 110.31
3
1 ST = € 2.29
€ 87.14
5
1 ST = € 2.26
€ 86.04
10
1 ST = € 2.26
€ 86.03
25
1 ST = € 2.24
€ 84.94
Volume discounts vary depending on the seller
You save € 0.00
Total (1 st = € 2.90)
€ 110.31
plus VAT.
Highlights & Details
MILLI-LIGHT ID
- Content: 38 pc(s)
- No. of rows: 2
- Total number of pins: 14
Technical specifications
- Please review product datasheet for further information.
- Packaging type
Tube
- Product type
Built-in SIL socket (standard)
- No. of rows
2
- Features
+ locking mechanism
- CS
2 mm
- Total number of pins
14
- Nominal current
1 A
- Nominal current - rounded value
1 A
- Content
38 pc(s)
- Dim
- Connection
SMT
- Coating thickness (PCB side)
1.905 µm
- Connector coating thickness
0.381 µm
- Case material
High temperature resistant thermoplastic
- Manufacturer part #
873401424
- Factory colour
Black
- Contact material
Phosphorus bronze
- Board contact surface
Tin
- Connector contact surface
Gold
- Nominal voltage
125 V
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Max. temperature
+105 °C
- Min. temperature
-55 °C
- Type
MOL Power & Signal Sol.
- Engineering Part No
87340-1424
- Engineering Series Name
2MM VLPR II RECEPT
- Engineering Series No
87340
Documents & Downloads
Datasheet
Datasheet 2450344 Molex Built-in SIL socket (standard) Total number of pins 14 Contact spacing: 2 mm 873401424 38 pc(s) Tube
User & Safety Instructions
User & Safety Instructions 2450344 Molex Built-in SIL socket (standard) Total number of pins 14 Contact spacing: 2 mm 873401424 38 pc(s) Tube
Circuit diagramm
Circuit diagramm 2450344 Molex Built-in SIL socket (standard) Total number of pins 14 Contact spacing: 2 mm 873401424 38 pc(s) Tube
Description
2.00mm Pitch Milli-Grid Receptacle, Surface Mount (Very Low Profile), Top Entry, with Locating Pegs, 0.38µm Gold (Au) Plating, 14 Circuits, Lead-Free, Tube, Black
