Buy Molex Pin strip (standard) No. of rows: 1 Pins per row: 4 901200124 1 pc(s) Tray

Highlights & Details

C-GRID 111

Content 1 pc(s)
No. of rows 1
Pins per row 4

Technical specifications

Breakaway: YesRecommended PCB thickness: 1.6 mmProcess temperature max. 230 °C.

Packaging type: Tray

No. of rows: 1

Pins per row: 4

Total number of pins: 4

CS: 2.54 mm

Connection: Soldering

Factory colour: Black

Nominal voltage: 350 V DC/AC

Nominal current: 3 A

Nominal current - rounded value: 3 A

Contact surface: Tin plated

Contact material: Brass

Case material: Polyester

Separable: Yes

Dim: 2.54mm Pitch

Connector orientation: Perpendicular (to the PCB)

Manufacturer part #: 901200124

Content: 1 pc(s)

Dimensions: 2.54mm Pitch mm

Engineering Part No: 901200124

Engineering Series Name: SR HDR VERT

Engineering Series No: 90120

Leading contact (PE): No

Connector contact surface: Tin

Board contact surface: Tin

Type: Molex MOL Power & Signal Sol.

Mating cycles: 30

Range of uses: Signal, cable to PCB

Pin length: 2.9 mm

RoHS-compliant: Yes

Max. temperature: +125 °C

Min. temperature: -55 °C

UKCA: yes

Product type: Pin strip (standard)
