Monacor CDX1-1742/8 PA horn driver RMS capacity=50 W 8 Ω
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Net weight: 1.4 kg
- Transmission technology: Cable
- Frequency range 1200-20000 Hz
- Nominal capacity (RMS) 50 W.
- Characteristic sound pressure 106 dB/W/m
- Mounting hole: Depending on the horn
- Installation depth: Depending on the horn
- Dimensions 100 x 53.5 mm
- Outer diameter: 100 mm
- Width 100 mm
- Height: 100 mm
- Depth: 53.5 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 1.4 kg
- Speaker type 1"
- Gross weight: 1.55 kg
- Impedance (Z) 8 Ω
- Rec. Cut-off frequency (fmax.) (12 dB/Oct):2000 Hz
- Music load capacity (MAX) 100 W
- Voice coil diameter 44 mm
- Ø 76 mm (2x M6), Ø 57 mm (3x M6)
- Voice coil material: Copper-coated aluminum flat wire
- Outlet opening 25 mm
- Product type
PA horn driver
- RMS capacity
50 W
- Max. load
100 W
- Min. frequency
1200 Hz
- Max. frequency
20000 Hz
- Frequency range
1200 Hz - 20000 Hz
- Impedance
8 Ω
- Weight
1.4 kg
- (Ø)
100 mm
- Width
100 mm
- Height
100 mm
- Factory colour
Black
- Depth
53.5 mm
- Sound pressure
106 dB
- Speaker size (inch)
1 inch
Documents & Downloads
Datasheet
Datasheet 3340864 Monacor CDX1-1742/8 PA horn driver RMS capacity=50 W 8 Ω
User & Safety Instructions
User & Safety Instructions 3340864 Monacor CDX1-1742/8 PA horn driver RMS capacity=50 W 8 Ω
Description
PA HORN DRIVER, 50 W, 8 Ω
High-quality 25 mm compression driver (1") with 44 mm voice coil (1.75") and ferrite magnet One-part polyamide membrane and crimp sound-castle soft-tone membrane of the next generation Recommended crossover frequency 2000 Hz (12 dB/oct.) 2-hole and 3-hole screw mounting
This text is machine translated.
High-quality 25 mm compression driver (1") with 44 mm voice coil (1.75") and ferrite magnet One-part polyamide membrane and crimp sound-castle soft-tone membrane of the next generation Recommended crossover frequency 2000 Hz (12 dB/oct.) 2-hole and 3-hole screw mounting
This text is machine translated.
Features
- Impedance (Z) 8 Ω
- Transmission technology: Cable
- Frequency range 1200-20000 Hz
- Rec. Cut-off frequency (fmax.) (12 dB/Oct):2000 Hz
- Nominal capacity (RMS) 50 W.
- Music load capacity (MAX) 100 W
- Characteristic sound pressure 106 dB/W/m
- Voice coil diameter: Ø 44 mm
- Voice coil material: Copper-coated aluminum flat wire
- Outlet opening Ø 25 mm
- Mounting hole: Depending on the horn
- Installation depth: Depending on the horn
- Ø 76 mm (2x M6),;Ø 57 mm (3x M6)
- Dimensions: Ø 100 mm x 53.5 mm
- Outer diameter: Ø 100 mm
- Width: Ø 100 mm
- Height: Ø 100 mm
- Depth: 53.5 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 1.4 kg
- Packing: 1
- Speaker type 1"
- Packaging dimensions (W x H x L) 0.14 x 0.07 x 0.17 m
- Gross weight: 1.55 kg
- Net weight: 1.4 kg
