Monacor CF1540HD/8 15 inch PA subwoofer 1200 W 8 Ω
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Net weight: 11.2 kg
- Transmission technology: Cable
- Frequency range 35-2000 Hz
- Nominal capacity (RMS) 1200 W.
- Characteristic sound pressure 97 dB/W/m
- Installation opening: 354 mm
- Installation depth: 184 mm
- Dimensions 393 x 184 mm
- Outer diameter: 393 mm
- Width 393 mm
- Height: 393 mm
- Depth: 184 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 11.2 kg
- Speaker type 15"
- Gross weight: 12.6 kg
- Impedance (Z) 8 Ω
- Resonant frequency (fs): 40.8 Hz
- Music load capacity (MAX) 2400 W
- Voice coil diameter 100 mm
- Hole diameter 367-374 mm
- Suspension compliance (Cms) 0.11 mm / N
- Moving mass (MMS): 145.53 g
- Mechanical quality (QMS): 5.591
- Electrical quality (QES): 0.323
- Overall quality (Qts): 0.305
- Equivalent volume (Vas): 108.3 l
- Direct current resistance (Re) 5.15 Ω
- Power factor (WxL) 24.40 Tm
- Voice coil former (Le):1.22 mH
- Voice coil former: Glass fiber
- Linear deflection (XMAX): ± 10.5 mm
- Effective Membrane area (SD): 855.3 cm2
- Magnet weight: 3.18 kg
- Voice coil length 25 mm
- Voice coil material: Copper wire
- Product type
PA subwoofer
- Speaker size (inch)
15 inch
- RMS capacity
1200 W
- Max. load
2400 W
- Min. frequency
35 Hz
- Max. frequency
2000 Hz
- Impedance
8 Ω
- Sound pressure
97 dB
- Recess diameter
35.4 cm
- Recess depth
18.4 cm
- Weight
11.2 kg
- Factory colour
Black
- Frequency range
35 Hz - 2000 Hz
- Depth
18.4 cm
- Height
39.3 cm
- Width
39.3 cm
Documents & Downloads
Datasheet
Datasheet 3340897 Monacor CF1540HD/8 15 inch PA subwoofer 1200 W 8 Ω
User & Safety Instructions
User & Safety Instructions 3340897 Monacor CF1540HD/8 15 inch PA subwoofer 1200 W 8 Ω
Description
PA SUBWOOFER, 1200 W, 8 Ω
Glass-fiber reinforced paper diaphragm with weather-proof impregnation Two dismantling rings Optimised double suspension Balanced ventilation provides for improved cooling
This text is machine translated.
Glass-fiber reinforced paper diaphragm with weather-proof impregnation Two dismantling rings Optimised double suspension Balanced ventilation provides for improved cooling
This text is machine translated.
Features
- Impedance (Z) 8 Ω
- Transmission technology: Cable
- Frequency range 35-2000 Hz
- Resonance frequency (fs): 40.8 Hz
- Nominal capacity (RMS) 1200 W.
- Music load capacity (MAX) 2400 W
- Characteristic sound pressure 97 dB/W/m
- Suspension (Cms): 0.11 mm/N
- Moving earth (Mms): 145.53 g
- Mechanical quality (Qms): 5.591
- Electrical quality (QES): 0.323
- Overall quality (Qts): 0.305
- Equivalent volume (Vas): 108.3 l
- Direct current resistance (Re): 5.15 Ω
- Power factor (WxL) 24.40 Tm
- Voice coil former (Le): 1.22 mH
- Voice coil diameter: Ø 100 mm
- Voice coil length 25 mm
- Voice coil material: Copper wire
- Voice coil former: Glass fiber
- Linear deflection (XMAX): ± 10.5 mm
- Effective Membrane area (Sd): 855.3 cm²
- Magnet weight: 3.18 kg
- Mounting hole dia. 354 mm.
- Installation depth: 184 mm
- Hole diameter: Ø 367-374 mm
- Dimensions: Ø 393 mm x 184 mm
- Outer diameter: Ø 393 mm
- Width: Ø 393 mm
- Height: Ø 393 mm
- Depth: 184 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 11.2 kg
- Packing: 1
- Speaker type 15"
- Packaging dimensions (W x H x L) 0.435 x 0.2 x 0.435 m
- Gross weight: 12.6 kg
- Net weight: 11.2 kg
