Monacor ESP-1000AB PA wall speaker 1.5 W White 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Monacor ESP-1000 FROM ELA Wall Speaker
- EN -54-24 certification
- A/B speaker distribution according to EN 60849
- 100-V transformer technology
Technical specifications
- Product type
PA wall speaker
- Operating voltage
100 V
- RMS capacity
1.5 W
- Max. load
6 W
- Max. sound pressure
100 dB
- Features
Ceiling speaker
- Material
Plastic
- Length
100 mm
- Width
100 mm
- Content
1 pc(s)
- Weight
1.98 kg
- Factory colour
White
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1780958 Monacor ESP-1000AB PA wall speaker 1.5 W White 1 pc(s)
Description
This double speaker is specially designed for use in PA sound systems designed and can be used as a wall or ceiling loudspeaker can be used. It is equipped with a certification according to EN 54-24 for use in voice alarm systems. The rugged metal housing is equipped with two loudspeakers, both of which has its own transformer for the operation in 100 V systems. The device is therefore suitable for PA systems with A/B wiring according to EN 60849. The selection of the terminals, you can switch between three performance values can be selected.
This text is machine translated.
This text is machine translated.
Features
- EN -54-24 certification
- A/B speaker distribution according to EN 60849
- 100-V transformer technology
- 2 x 13-cm wide-band speaker
- Two independent transformers with power taps, each with 6/3/1.5 W
- Connection takes place via 2 ceramic screw terminals inside the casing
- Rear open plastic casing with metal front grille.
Scope of delivery
- Aluminum mounting bracket
- Screws
- Dowels.
