Monacor PA-4040MPX PA preamplifier 4-channel 4-zone
EAN:
Part number:
Item no:
Highlights & Details
Monacor PA -4040 MPX ELA-pre-amplifier
- 4-zone mixer for universal multi-room" - sound reinforcement applications
- This text is machine translated.
Technical specifications
- Mic/Line1-3: 5mV/4 kOhm, 100 mV/10 kOhm
- Line4-5: 100mV/30 kOhm
- Phone Paging: 40 mV/5 kOhm
- Line (zone): 1.7 V, sym.
- Line (Mix): 3.95 V
- Monitor speakers: 8 Ohm/1W
- Frequency range:50-1 7000 Hz
- Depth: +/-10 dB/100 Hz
- High: +/-10 dB/10 kHz
- Mic:> 65 dB
- Line:> 75 dB
- Distortion factor:< 1%
- Permissible operating temperature: 0-40°C
- Power supply 230 VWechsel/50 Hz/20 VA, 24 V DC current /600mA
- Product type
PA preamplifier
- No. of zones
4-zone
- Dim
(L x W x H) 22 x 48.2 x 13.3 cm
- Weight
4.5 kg
- No. of channels
4-channel
- Width
48.2 cm
- Height
13.3 cm
- Length
22 cm
- Interfaces
Mic input combo jack (XLR, 6.35 mm jack)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1332321 Monacor PA-4040MPX PA preamplifier 4-channel 4-zone
User & Safety Instructions 1332321 Monacor PA-4040MPX PA preamplifier 4-channel 4-zone
Description
Features
- 4 zones with any routing possibility of all input channels
- 3 inputs microphone/line via combi-sockets
- 2 inputs LINE stereo via phono sockets
- Input channels with gain setting, 2-way tone control and zones routing switch
- Microphone inputs with individually switchable +15 V phantom power
- Priority function for channels 1-3, switchable
- Independent paging input, on all zones can be routed
- 4 zone outputs, individually adjustable
- Connection for monitor loudspeakers
- Level control of zones and monitor-VU meter
- Adjustable headphone output
- Mains or 24 V emergency power mode"
