Monacor RL-1ENABDS PA ceiling speaker 1.5 W White 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Monacor RL-1 ENABDS ELA speaker
- EN -54-24 certification
- A/B speaker distribution according to EN 60849
- 100-V transformer technology
Technical specifications
- Product type
PA ceiling speaker
- Operating voltage
100 V
- RMS capacity
1.5 W
- Max. load
6 W
- Max. sound pressure
101 dB
- Features
Ceiling speaker
- Material
Metal
- Length
21 cm
- Content
1 pc(s)
- Weight
2.3 kg
- Factory colour
White
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1780967 Monacor RL-1ENABDS PA ceiling speaker 1.5 W White 1 pc(s)
Description
These loudspeakers in a robust aluminum casing are specially designed for use in PA sound systems. They are equipped with a certification according to EN 54-24 for use in voice alarm systems. The speakers have a transformer for the operation in 100 V systems. On the choice of connection cables can be between three performance values can be selected. The model RL-1 ENABDS is equipped with two connection cables, two transmitters and a loudspeaker with a double voice coil and is therefore suitable for PA systems with A/B wiring according to EN 60849. With your mounting brackets allow the speaker to the wall or ceiling.
This text is machine translated.
This text is machine translated.
Features
- EN -54-24 certification
- A/B speaker distribution according to EN 60849
- 100-V transformer technology
- 13-cm wide-band speaker with double voice coil
- 2 x 100-V transformer with power taps on the cable 6/3/1.5 W
- Connection takes place via 2 x 4-wire cable (length 1.5 m)
- Metal casing with Front protective grille.
Scope of delivery
- Swivel-tilt bracket
- Mounting material.
