Monacor SL-250SW/EN PA speaker cabinet 250 W Black 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Net weight: 19.7 kg
- 100 V or low impedance transmission technology
- Frequency range 85-19000 Hz
- Characteristic sound pressure 99.6 dB/W/m
- Dimensions 425 x 418 x 390 mm
- Width 425 mm
- Height: 418 mm
- Depth: 390 mm
- Colour, black
- Ass. Operating temperature -25 °C to +70 °C
- Weight: 19.7 kg
- Gross weight: 23.5 kg
- Max. Nominal sound pressure 122.5 dB
- Inputs: Screw terminal
- Angle of radiation H60°/V70°
- Impedance: 8 Ω
- Angle of radiation horizontal 60°
- Angle of radiation vertical 70°
- Active/passive: Passive
- 2-way coaxial
- ABS casing material
- Nominal load 250/125/63 W
- Total load capacity 250 W.
- 12" (30 cm) Woofer
- Number of built-in LS chassis: 2
- Speaker size 30 cm (12")
- Mounting unit: Mounting bracket
- IP66 protection rating
- Tweeter: Tweeter driver
- Product type
PA speaker cabinet
- Operating voltage
100 V
- RMS capacity
250 W
- Max. load
250 W
- Impedance
8 Ω
- Max. sound pressure
122.5 dB
IP66
- Material
Acrylonitrile butadiene styrene
- Length
39 mm
- Width
42.5 mm
- Content
1 pc(s)
- Weight
19.7 kg
- Factory colour
Black
- Height
41.8 mm
- Sound pressure
99.6 dB
- Frequency range
85-19000 Hz
Documents & Downloads
Datasheet
Datasheet 3340501 Monacor SL-250SW/EN PA speaker cabinet 250 W Black 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3340501 Monacor SL-250SW/EN PA speaker cabinet 250 W Black 1 pc(s)
Description
Weatherproof PA speaker box, 250 W,
With EN-54-24 certification
100-V transmission technology or 8 Ω operation 2-way bass reflex system 30 cm coaxial loudspeaker (12") with tweeter driver and frequency separating filter Very good sound characteristics IP66-tested ABS-casing with metallic protection grille countersunk connection terminal plate and PG-cable bushing Safety cable in the scope of delivery Wall bracket made of stainless steel
This text is machine translated.
With EN-54-24 certification
100-V transmission technology or 8 Ω operation 2-way bass reflex system 30 cm coaxial loudspeaker (12") with tweeter driver and frequency separating filter Very good sound characteristics IP66-tested ABS-casing with metallic protection grille countersunk connection terminal plate and PG-cable bushing Safety cable in the scope of delivery Wall bracket made of stainless steel
This text is machine translated.
Features
- Active/passive: Passive
- 100 V or low impedance transmission technology
- Load capacity
- Total: 250 W
- Nominal load 250/125/63 W
- Impedance: 8 Ω
- Frequency range 85-19000 Hz
- 2-way coaxial
- 12" (30 cm) Woofer
- Tweeter: Tweeter driver
- Number of built-in LS chassis: 2
- Speaker size 30 cm (12")
- Characteristic sound pressure 99.6 dB/W/m
- Max. Nominal sound pressure 122.5 dB
- Angle of radiation H60°/V70°
- Angle of radiation horizontal 60°
- Angle of radiation vertical 70°
- ABS casing material
- Colour, black
- Mounting unit: Mounting bracket
- IP66 protection rating
- Ass. Operating temperature -25 °C to +70 °C
- Dimensions 425 x 418 x 390 mm
- Width 425 mm
- Height: 418 mm
- Depth: 390 mm
- Weight: 18.9 kg
- Inputs: Screw terminal
- Packaging dimensions (W x H x L) 0.425 x 0.39 x 0.418 m
- Gross weight: 20 kg
- Net weight: 18.9 kg
