Monacor TF1225E/8 12 inch 30.5 cm Subwoofer 300 W 8 Ω
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Net weight: 4.4 kg
- Transmission technology: Cable
- Frequency range 5-3000 Hz
- Nominal capacity (RMS) 300 W.
- Characteristic sound pressure 96 dB/W/m
- Installation opening: 283 mm
- Installation depth: 139 mm
- Dimensions 309 x 139 mm
- Outer diameter: 309 mm
- Width 309 mm
- Height: 309 mm
- Depth: 139 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 4.4 kg
- Speaker type 12"
- Gross weight: 5 kg
- Impedance (Z) 8 Ω
- Resonant frequency (fs): 52.6 Hz
- Music load capacity (MAX) 600 W
- Voice coil diameter 64 mm
- Hole diameter 297 mm
- Suspension compliance (Cms) 0.17 mm / N
- Moving mass (MMS): 54.04 g
- Mechanical quality (QMS): 3.513
- Electrical quality (QES): 0.368
- Overall quality (Qts): 0.333
- Equivalent volume (Vas): 67 l
- Direct current resistance (Re) 6.42 Ω
- Power factor (WxL) 17.66 Tm
- Voice coil former (Le):1.32 mH
- Voice coil former: Polyimide
- Linear deflection (XMAX): ± 5 mm
- Effective Membrane area (SD): 590.93 cm2
- Magnet weight: 1.4 kg
- Voice coil length 14.5 mm
- Voice coil material: Copper wire
- Product type
Subwoofer
- Speaker size (inch)
12 inch
- Speaker size (cm)
30.5 cm
- RMS capacity
300 W
- Max. load
600 W
- Min. frequency
5 Hz
- Max. frequency
3000 Hz
- Impedance
8 Ω
- Sound pressure
96 dB
- Recess diameter
28.3 mm
- Recess depth
13.9 mm
- Weight
4.4 kg
- Factory colour
Black
- Frequency range
5 Hz - 3000 Hz
- Depth
13.9 mm
- Height
30.9 mm
- Width
30.9 mm
Documents & Downloads
Datasheet
Datasheet 3340908 Monacor TF1225E/8 12 inch 30.5 cm Subwoofer 300 W 8 Ω
User & Safety Instructions
User & Safety Instructions 3340908 Monacor TF1225E/8 12 inch 30.5 cm Subwoofer 300 W 8 Ω
Description
PA WOOFER, 300 W, 8 Ω
The TF series chassis is characterized by excellent price/performance ratio with simultaneous very good sound characteristics and is thus predestined for use in powerful PA speaker systems with strong sound.
High capacity 30.5 cm PA woofer (12") with Hohem efficiency High-quality, with Kevlar fibers reinforced paper diaphragm Excellent frequency response linearity and broadband stability Sturdy steel sheet basket All-round chassis for PA systems with Hohem quality claim
This text is machine translated.
The TF series chassis is characterized by excellent price/performance ratio with simultaneous very good sound characteristics and is thus predestined for use in powerful PA speaker systems with strong sound.
High capacity 30.5 cm PA woofer (12") with Hohem efficiency High-quality, with Kevlar fibers reinforced paper diaphragm Excellent frequency response linearity and broadband stability Sturdy steel sheet basket All-round chassis for PA systems with Hohem quality claim
This text is machine translated.
Features
- Impedance (Z) 8 Ω
- Transmission technology: Cable
- Frequency range 5-3000 Hz
- Resonance frequency (fs): 52.6 Hz
- Nominal capacity (RMS) 300 W.
- Music load capacity (MAX) 600 W
- Characteristic sound pressure 96 dB/W/m
- Suspension (Cms): 0.17 mm/N
- Moving earth (Mms): 54.04 g
- Mechanical quality (Qms): 3.513
- Electrical quality (QES): 0.368
- Overall quality (Qts): 0.333
- Equivalent volume (Vas): 67 l
- Direct current resistance (Re): 6.42 Ω
- Power factor (WxL) 17.66 Tm
- Voice coil former (Le): 1.32 mH
- Voice coil diameter: Ø 64 mm
- Voice coil length 14.5 mm
- Voice coil material: Copper wire
- Voice coil former: Polyimide
- Linear deflection (XMAX): ± 5 mm
- Effective Membrane area (Sd): 590.93 cm²
- Magnet weight: 1.4 kg
- Mounting hole dia. 283 mm.
- Installation depth: 139 mm
- Hole diameter: Ø 297 mm
- Dimensions: Ø 309 mm x 139 mm
- Outer diameter: Ø 309 mm
- Width: Ø 309 mm
- Height: Ø 309 mm
- Depth: 139 mm
- Colour, black
- Ass. Operating temperature 0-40 °C
- Weight: 4.4 kg
- Packing: 1
- Speaker type 12"
- Packaging dimensions (W x H x L) 0.33 x 0.16 x 0.33 m
- Gross weight: 5 kg
- Net weight: 4.4 kg
