Monitoring relay 1 maker Finder 19.50.0.024.0000 1 pc(s)
EAN:
Part number:
Item no:
Product type
Monitoring relay
Functions
Voltage
Contact type
1 maker
Switching voltage (max.)
24 V DC/AC
Type
19.50.0.024.0000
Datasheet (PDF)
Number
Total (€ 53.77 / piece)
€ 68.90
-22 %
€ 53.77
plus VAT.
Only 7 Piece(s) available
Highlights & Details
Analogue value generator 0 – 10 V, series 19.50.0.024
- 35 mm rail (EN 60715) mounting
- LED indication
- Positive safety logic (healthy conditions - output relay energised)
Technical specifications
- Input/output signal: (Imax. 20 mA, short-circuit-proof) 0 – 10 V/DC
- Product type
Monitoring relay
- Type
19.50.0.024.0000
- Functions
Voltage
- Operating voltage
24 V DC
24 V AC
- Contact type
1 maker
- Switching voltage (max.)
24 V DC/AC
IP20
- Min. temperature
-20 °C
- Max. temperature
+50 °C
- Width
17.5 mm
- Height
60.8 mm
- Depth
84 mm
- Dim
(W x H x D) 17.5 x 60.8 x 84 mm
- Content
1 pc(s)
- Type
Analogue value generator 0 – 10 V
- Switching voltage
(Feedback) 24 V DC/AC
- Switching current
(Feedback, AC/DC) 10/100 mA
- Type
19.50.0.024.0000
- Ambient temperature
-20 - +50 °C
- Operating voltage
24 V DC/AC
Documents & Downloads
Datasheet
Datasheet 504707 Monitoring relay 1 maker Finder 19.50.0.024.0000 1 pc(s)
User & Safety Instructions
User & Safety Instructions 504707 Monitoring relay 1 maker Finder 19.50.0.024.0000 1 pc(s)
Description
For industrial and building management systems. Analogue value output modules are used as a precautionary measure to replace a specified or faulty analogue value from 0 – 10 V with a manually adjustable value. In the H switch position (manual), an adjustable signal is available at the output on the front knob instead of the value generated in automatic mode. The values of the analogue value specified by the regulation process and the set analogue value are shown by three green LEDs. A non-automatic operational state is indicated by a flashing yellow LED. Typical applications are manual provision of default variables in water mixing valves, regulation of fresh air to recirculating air ratios, industrial analogue regulation processes and so on.
Hints
Approvals: CE.
