MSI Z890-S Pro Motherboard PC base #####Intel® 1851 Form factor (details) ATX Motherboard chipset Intel® Z890
EAN:
Part number:
Item no:
MSI Z890-S Pro Motherboard
Highlights & Details
- Intel LGA 1851 (socket V1) Intel core ultra (series 2)
- PC ATX Intel Z890 Realtek ALC897 7.1 channels
- DDR5 SDRAM 4 DIMM RAM maximum: 256 GB
- HDD & SSD M.2, SATA III RAID support Number of supported storage drives: 4
- 2.5 Gigabit Ethernet WLAN Wi-Fi 7 (802.11b) Bluetooth 5.4
- This text is machine translated.
Technical specifications
- HDMI 1
- Lamp color RGB Mystic Light
- Colour, black
- Supported processor models: Intel core ultra (2 series)
- Socket Intel LGA 1851
- Chipset: Intel® Z890
- BIOS: EFI AMI
- Formfactor: ATX
- Suitable for free multipliers: Yes
- Memory max. 256 GB
- Memory spaces 4
- Memory per disk space: 64GB
- Memory type: DDR5 SDRAM
- RAM clock 4800 MHz;6400 MHz;8800 MHz
- Memory channels: Two-channel
- Memory type: Non-ECC;un-buffered
- Controller in CPU: Yes
- LAN (RJ45): 1
- USB 3.1/0
- USB 3.0/8
- USB 2.0/0
- USB C 1
- VGA 0
- DisplayPort 1
- Microphone: 1
- Line out 3.5 mm jack 4
- S/PDIF-out (optical): 1
- PCIe 5.0 1x PCIe x16
- PCIe 3.0 2x PCIe x16; 1x PCIe x1
- Mainboard Power 24-pin
- CPU power 2x 8-pin
- SATA 3:4
- M.2: 3
- M.2 Length max.: 110mm
- M.2 Connector: M
- USB header USB 2.0: 4
- USB header USB 3.0: 2
- USB-HEADER USB C: 1
- 4-pin fan PWM 7
- Sound chip: 7.1 channels, Realtek ALC897
- LAN: Intel® I225-V 2.5Gbit
- Multi GPU: Yes
- Multi GPU Mode: Not supported
- RAID SATA 0, 1, 5, 10
- RAID M.2: 0;1;5
- Weight (g): 2100
- Width (cm): 30.50
- Depth (cm): 24.40
- Internal graphics: Yes
- Available slots: 6
- Product type
Motherboard
- Chipset
Intel® Z890
#####Intel® 1851
- Form factor
ATX
- Processor/type
Intel Core Ultra (Series 2)
- RAM type
DDR5 RAM
- Clock speed
4800 MHz
6400 MHz
8800 MHz
- RAM / Max. upgrade
256 GB
- Interfaces
DisplayPort
Audio line out
Microphone input
S/PDIF (optical)
HDMI™
- No. of DDR5 slots
4 x
- No. of Gigabit LANs
1 x
- No. of PCIe x16
3 x
- No. of PCIe x1
1 x
- No. of USB 2.0 ports
4 x
- No. of USB type A 3.0 ports
8 x
- No. of USB 3.2 2nd Gen (USB 3.1)
1 x
- No. of USB 3.0 ports
1 x
- No. of SATA III ports
4 x
- Bluetooth
5.4
- Bluetooth
Yes
- Factory colour
Silver
White
- Depth
304.8 mm
- Height
100 mm
- Width
243.8 mm
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- No. of USB type A 3.1 / 3.2 1st Gen
6 x
- 10/100/1000 Mbps ports
1 x
- Range of use
PC
- Wi-Fi
Yes
- UKCA
yes
- Ethernet LAN
yes
- Number of memory slots
4
- Number of M.2 (M) slots
3
- Intel Extreme Memory Profile (XMP)
yes
- Maximum internal memory supported by processor
256 GB
- USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
- Total number of SATA connectors
4
- Number of HDDs supported
7
- Supported memory clock speed (max)
8800 MHz
- RAID support
yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
- Thunderbolt ports quantity
1
- Number of storage drives supported
4
