MUNK Günzburger Steigtechnik 10120 Aluminium Ladder Set-up requires tools Operating height (max.): 6.9 m
EAN:
Part number:
Item no:
Technical specifications
- External test certificate: 2228711KAU-003: 2017-11-22
- Height of rung / step height: 30 mm
- Width of traverse: 1.2 m.
- Product type
Ladder
- Working height range
6.1 m - 7 m
- Material
Aluminium
- Length
5.82 m
- No. of rungs/steps
20
- Step depth
30 mm
- Operating height (max.)
6.9 m
- External width
420 mm
- Design type
To lean on
- Features
Set-up requires tools
- Steps
280 mm
- Load capacity (max.)
150 kg
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2271470 MUNK Günzburger Steigtechnik 10120 Aluminium Ladder Set-up requires tools Operating height (max.): 6.9 m
Certificate
Certificate 2271470 MUNK Günzburger Steigtechnik 10120 Aluminium Ladder Set-up requires tools Operating height (max.): 6.9 m
Description
Stainless steel ladder made of aluminum stable rectangular tube beams, square sprouts fluted on both sides 30 x 30 mm 4-way crimped rung / spar connection rung distance: 280 mm conductor width: 420 mm (without traverse) Standard traverse with non-slip conductor shoes in optimum width to the selected product for a safe stand and rise on landing ladders above 3.0 m. The cross rail is supplied loose and is bolted twice to the lower end of the beam Maximum load: 150 kg
